WEIDMULLER 2440000000 Signal Male Header
The Weidmueller OMNIMATE Signal series SL 2.50 male header is designed for wave soldering with a 2.50 mm pitch. It features a straight (180°) connection to PCB, enclosed housing, and is packaged in a box. With 11 poles, it complies with IEC, UL, and CSA standards, rated for 320V/6A or 150V/5A. Made with black PA 66 insulation, tinned copper contact surfaces, and dimensions suited for robust industrial applications, it offers reliable connections for electronic assemblies and circuit boards.
WEIDMULLER 2440000000 Signal Male Header Specifications:
- Pitch: 2.50 mm (0.984 inch)
- Poles: 11
- Housing: Closed (G), black PA 66 insulation
- Contact Material: Copper alloy, tinned surface
- Contact Dimensions: 0.8x0.8 mm
- Solder Pin Length: 3.2 mm ±0.17 mm
- Solder Eyelet Hole Diameter: 1.3 mm ±0.1 mm
- Dimensions: Width 29.4 mm, Height 13.3 mm, Depth 8.1 mm
- Operating Temperature: -40°C to +105°C
- Rated Voltage: 320V IEC / 150V UL, Rated Current: 6A IEC / 5A UL
- IP Rating: IP00 (touch-safe protection), 25 cycles durability
Buy the Buy Weidmüller Signal Series Male Header Part Number 2440000000 Online
Purchase the Weidmueller Signal series male header with 11 poles that ensures reliable PCB connections. Featuring a 2.50 mm pitch, durable black PA 66 housing, and tinned copper contacts, it is perfect for precise electronic and industrial applications. Rated for 320V/6A IEC and UL standards, this component withstands high temperatures and frequent connections. Packaged in a box, it offers excellent durability, safety, and ease of assembly, making it an ideal choice for automation and circuit board assembly needs.
Get Weidmüller 2440000000 today—built for precision, reliability, and long-lasting durability in electronic assemblies.
