WEIDMULLER 2473060000 Power Terminal Block
The LLFS series power terminal block provides a sturdy, high-current connection solution designed for power electronics applications such as solar inverters, frequency converters, servo-controllers, and power supplies. It features 8 poles with push-in connection, a 7.50 mm pitch, and a solder pin length of 5 mm. Made from flame-retardant Wemid (PA) material with tinned copper contacts, it supports rated voltages up to 1000 V and currents up to 41A. Its compact dimensions, IP20 touch-safe protection, and easy PCB mounting make it ideal for demanding power systems requiring reliable, secure connections.
WEIDMULLER 2473060000 Power Terminal Block Specifications:
- Type: LLFS 7.50/08/90V 5.0SN BK BX
- Number of poles: 8
- Pitch: 7.5mm (0.295 inch)
- Solder pin length: 5mm
- Width: 61mm (2.402 inch)
- Height: 30.56mm (1.203 inch)
- Depth: 20.05mm (0.789 inch)
- Weight: 32.69g
- Material: Wemid (PA), black, flame-retardant V0 UL 94
- Contact material: Tinned copper (E-Cu)
- Insulation strength: 210°C
- Rated voltage: 1000 V
- Rated current: 41A (IEC), 37A (UL/CSA), max 8 poles
- Wire connection: Push-in, suitable for solid and flexible conductors (0.25 mm² to 6 mm²)
- Solder pin: 1 per pole, length 5mm
- Solder eyelet diameter: 2mm with ±0.1mm tolerance
- Operating temperature range: -40°C to 120°C
- Protection rating: IP20
- Flammability: UL 94V-0
Buy the Buy Weidmuller Power Series LLFS Part Number 2473060000 Online
Purchase the Weidmuller Power Terminal Block Series LLFS, Part Number 2473060000, online today. This high-current, 8-pole terminal features push-in connection technology, a 7.50 mm pitch, and rated voltages up to 1000 V and currents of 41A. Ideal for power electronics, solar inverters, and servo controllers, it offers IP20 touch-safe protection, easy PCB mounting, and reliable tinned copper contacts. Ensure the safety and efficiency of your power system with this premium, flame-retardant component available for quick online ordering.
Order your Weidmuller Series LLFS 2473060000 power terminal today and ensure secure, high-current connections for your power electronics projects.
