WEIDMULLER 9995040000 LM 5.08/11/180 3.5SN OR BX
The WEIDMULLER LM 5.08/11/180 3.5SN OR BX is a robust PCB terminal block engineered for secure and efficient electrical connections in a variety of industrial applications. Its 5.08mm pitch and 11-pole configuration make it ideal for dense circuit board layouts. The 180° conductor outlet direction provides flexibility in routing wires. Constructed with a Wemid (PA) insulating material and featuring a clamping yoke connection, this terminal block ensures reliable performance and ease of use. It is suitable for conductor cross-sections up to 2.5 mm² and is rated for high voltage and current applications.
WEIDMULLER 9995040000 LM 5.08/11/180 3.5SN OR BX Specifications:
- Base Material: Copper alloy
- Coating: 1-3μm Ni,4-6μm SN
- Insulating Material: Wemid (PA)
- Color: Orange
- Pitch: 5.08 mm
- Number of Poles: 11
- Conductor Outlet Direction: 180°
- Conductor Cross-Section: 0.13 - 2.50 mm² (IEC) / 26 - 14 AWG (UL)
- Rated Voltage: 630 V (IEC) / 300 V (UL)
- Rated Current: 17.5 A (IEC) / 20 A (UL)
- Stripping Length: 6 mm
- Tightening Torque: 0.4 - 0.5 Nm
- Clamping Range: 0.2 - 2.5 mm²
- UL Flammability Rating: V-0
- Storage Temperature Min: -25 °C
- Storage Temperature Max: 55 °C
- Operating Temperature Min: -50 °C
- Operating Temperature Max: 120 °C
Buy the 9995040000 WEIDMULLER LM 5.08/11/180 3.5SN OR BX | myMectronic
Purchase the WEIDMULLER LM 5.08/11/180 3.5SN OR BX securely and efficiently through our online store.
Buy Now
