WEIDMULLER 8869400000 Relay Base
The relay base for RIDERSERIES RCM relays is designed with 2 CO contacts, providing reliable switching with a 12 A continuous current capacity. It features screw and PUSH IN wire connections, offering fast and secure wiring options. Its compact dimensions include a width of 27.2mm, height of 77mm, and depth of 61.5mm. The base is UL and CE certified, supporting operating temperatures from -40°C to 70°C, and has a protection degree of 1P20. Suitable for industrial automation, it ensures safe electrical isolation and robust performance in control systems.
WEIDMULLER 8869400000 Relay Base Specifications:
- Type: SCM 2CO
- Contacts: 2 CO contact
- Continuous Current: 12 A
- Rated Voltage: 250 VAC
- Max Switching Voltage: 400 V AC
- Width: 27.2 mm (1.071 inch)
- Height: 77 mm (3.031 inch)
- Depth: 61.5 mm (2.421 inch)
- Weight: 52.46 g
- Operating Temperature Range: -40°C to 70°C
- Protection Degree: 1P20
- UL Certification: E223759
- cURus Certification: E223759
- Flammability Rating: UL 94 V-0
- Insulation: Basic insulation at input/output, 2.5 kV dielectric strength
- Wire Connection: Screw connection, strip length 8mm, torque 0.5-0.7 Nm
- Clamp Range: 2.5 mm²
- Environmental Compliance: REACH SVHC Lead
Buy the Weidmueller Series RIDERSERIES RC M: SCM-I2CO
Purchase the Weidmueller relay base for RIDERSERIES RCM relays online today. Engineered for durability and precision, this relay base features 2 CO contacts, screw and push-in wire connections, and supports a continuous current of 12 A. Its compact design measures 27.2mm in width, 77mm in height, and 61.5mm in depth, ideal for control cabinets. Certified with UL and CE standards, it ensures safe operation from -40°C to 70°C, making it a reliable choice for industrial automation systems.
Get Weidmueller SCM-I2CO relay base today—built for reliable industrial automation with secure screw and push-in connections.
Frequently Asked Questions
Where can I buy WEIDMULLER 8869400000?
You can click on the BUY or RFQ button to purchase 8869400000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 8869400000?
You can download the 8869400000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 8869400000?
WEIDMULLER
