WEIDMULLER 1234570000 PCB Terminal
The PCB terminal with leaf spring connection from Weidmüller features a 5.08 mm pitch and a 90° conductor outlet. Designed for reliable, high-current connections, it supports conductor cross-sections from 0.13 to 2.5 mm² (AWG 26 to 14) and withstands voltages up to 600 V (IEC) and 300 V (UL). Its pressure clamp connection ensures secure wiring, and the tinned, orange insulating material provides excellent protection. Suitable for various industrial applications requiring robust, easy-to-assemble terminal blocks on printed circuit boards.
WEIDMULLER 1234570000 PCB Terminal Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 5
- Solder pin length: 3.5 mm
- Material: Tinned copper, Insulating material: Wemid (PA), Orange, RAL 2000
- Rated voltage: IEC 600 V, UL 300 V
- Rated current: IEC 24 A, UL 15 A
- Clamping range: 0.13 mm² to 2.5 mm²
- Conductor range: AWG 26 to AWG 14
- Maximum torque: 0.5 Nm
- Dimensions: Insulation length 20.32 mm (0.8 inch), Eyelet diameter 13 mm
- Protection: Touch-safe according to DIN VDE 470 and 57106, IP 20
- Operating temperature: -60°C to 120°C
- Flammability: UL 94 V-0
- Contact material: Copper alloy, Tinned surface
- Wire ferrules: DIN 46228 Pt 1 and Pt 4 compatible
Buy the Weidmueller 1234570000 – Reliable PCB Terminal for Industrial Applications
Purchase the Weidmueller PCB terminal with leaf spring connection now to ensure reliable circuit connections in your industrial projects. Featuring a 5.08 mm pitch, it supports conductor cross-sections from 0.13 to 2.5 mm² (AWG 26 to 14). With high voltage ratings up to 600 V (IEC) and 300 V (UL), the terminal provides excellent current capacity of 24 A (IEC) and 15 A (UL). Its pressure clamp connection guarantees a secure, vibration-proof connection, ideal for efficient, safe electronic assemblies in demanding environments. Order online today for swift delivery and quality assurance.
Order your Weidmueller Series1234570000 PCB terminal today and enhance your industrial wiring with dependable contact stability and secure connection.
