WEIDMULLER SL351690G Wave Solder Pin Header
The OMNIMATE Signal series BL/SL 3.50 pin headers are designed for wave soldering in 3.50 mm pitch with 16 poles, and feature a closed-side, THT solder connection. These orange-colored, tinned copper connectors support solder pin lengths of 3.2 mm, with a contact diameter of 1.2 mm. Suitable for PCB mounting, they are rated for 300V and 10A compliance, with UL and IEC approvals. Ideal for secure, reliable electrical connections in automation, control panels, and electronic systems, offering high durability and easy coding options.
WEIDMULLER SL351690G Wave Solder Pin Header Specifications:
- Pitch: 3.5 mm (0.138 inch)
- Number of Poles: 16
- Solder Pin Length: 3.2 mm (+0.1/-0.3 mm)
- Pin Diameter: 1.2 mm, octagonal, tinned copper
- Eyelet Hole Diameter: 1.4 mm
- Housing Color: Orange (RAL 2000)
- Material: PBT Insulating material, contact base CuSn
- Rated Voltage: 300V
- Rated Current: 10A
- Soldering Type: THT solder connection
- Mounting Orientation: 90° plug
- Touch-safe protection: Yes, compliant with DIN VDE
- Contact Resistance: 6.00 mΩ
- Operating Temperature Range: -60°C to 100°C
- Flammability Rating: UL 94 V0
- Max. Storage Humidity: 80%
- Compliance: IEC, UL, CSA approved
Buy the Buy Weidmuller Signal Series PIN Header Part Number SL351690G Online
Purchase the Weidmuller SL351690G pin headers online today to benefit from secure and high-quality wave soldering connections. These 16-pole PCB connectors are designed with precision, supporting 300V and 10A ratings, ensuring safety and longevity in electrical applications. Crafted with durable materials and UL and IEC certifications, they offer excellent mechanical stability, easy coding options, and compatibility with various automation systems. Order now for fast delivery and seamless integration into your electronic and control systems, enhancing reliability and performance.
Buy Weidmuller SL351690G high-performance pin headers now and ensure reliable, durable connections for your automation and control projects.
Frequently Asked Questions
Where can I buy WEIDMULLER SL351690G?
You can click on the BUY or RFQ button to purchase SL351690G from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part SL351690G?
You can download the SL351690G datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of SL351690G?
WEIDMULLER
