XP POWER IE0309S Industrial Power Module
The IE series offers compact, high-performance switching power supplies designed for industrial applications. With input voltage ranges, isolation options, and efficiency up to 23%, these units ensure reliable power delivery in harsh environments. Utilizing SIP or DIP packages, they feature excellent temperature tolerance from -40°C to +85°C, with optional 3000 VDC isolation for enhanced safety. Ideal for powering critical systems, these modules are UL94V-0 rated, convection-cooled, and come with a 3-year warranty, ensuring durability and safety compliance.
XP POWER IE0309S Industrial Power Module Specifications:
- Input Voltage Range: See table
- Reflected Ripple Current: 20 mA pk-pk through 12 pH inductor 5Hz to 20 MHz
- Input Reverse Voltage: None specified
- Protection: None specified
- Output Voltage: See table
- Minimum Load: Not specified
- Line Regulation: £1.2%/1% AVin
- Load Regulation: 10% for 20-100% load change
- Setpoint Accuracy: 1.1 MHrs to MIL-HDBK-217F at 25°C
- Ripple & Noise: 100 mV pk-pk max, 20 MHz bandwidth
- Temperature Coefficient: 0.02%/C
- Maximum Capacitive Load: 220 UF
- Efficiency: 23%
- Isolation Voltage (functional): 1000 VDC (option 3000 VDC)
- Isolation Resistance: Not specified
- Isolation Capacitance: 60 pF typical
- Switching Frequency: 40-150 KHz variable
- MTBF: >1.1 MHrs to MIL-HDBK-217F at 25°C
- Case Material: Non-conductive plastic UL94V-0, DIP solder coated brass
- Pin Material: SIP solder coated alloy 42
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +125°C
- Case Temperature: 100°C max
- Cooling: Convection-cooled
- Safety Certifications: CE & UKCA
Buy the Power Modules 0309S – Reliable Industrial Switching Power Supplies for Critical Systems
Discover the reliable industrial power solutions with our high-performance power modules. Designed for harsh environments, these units feature adjustable frequency, high efficiency, and UL certification. With optional 3000 VDC isolation, convection cooling, and a broad temperature range from -40°C to +85°C, they ensure durable operation in critical systems. Ideal for automation, manufacturing, and control systems, they deliver consistent power, protect your investments, and come with a 3-year warranty for peace of mind. Shop online today for trusted power solutions.
Order your Power Modules 0309S today and give your industrial projects the dependable power they need for peak performance.
Frequently Asked Questions
Where can I buy XP POWER IE0309S?
You can click on the BUY or RFQ button to purchase IE0309S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IE0309S?
You can download the IE0309S datasheet or visit the XP POWER website for support.
Who is the manufacturer of IE0309S?
XP POWER
