YOKOGAWA 260100FAFA DC Voltmeter
The YOKOGAWA 260 100 FAFA is a precision DC voltmeter designed for reliable performance in industrial environments. It utilizes a taut band mechanism for accurate readings and adheres to ANSI C-39.1 standards. This voltmeter is suitable for monitoring DC voltage levels in power systems, automation equipment, and other critical applications. It is available in various sizes and voltage ratings to meet diverse needs. For severe-duty applications requiring CSA, UL, or IEC compliance, contact the factory for specific models.
YOKOGAWA 260100FAFA DC Voltmeter Specifications:
- Accuracy: ±2% of full-scale AC rectifier type; ±3% of full scale (with 60 Hz sine wave at 25º C). Expanded-scale voltmeters: ±.5% of full scale value.
- ANSI Specification: All meters meet ANSI Specifications C-39.1
- Overload: Voltmeters (AC and DC) - 50% momentary, 20% sustained. Ammeters (AC and DC) momentary; 10 times the rated current for 10 consecutive intervals of .5 second with a 1 minute interval between successive applications; sustained: 20% for six hours.
- Scale Data: 90 degree rotation
- Insulation Level: All meters (except 1[1] ⁄2”), 2600 Vrms Hi-pot, 1[1] ⁄2”-1500 Vrms Hi-pot.
- Burden Data: AC ammeter-5 amps, 0.5 va, Max. 0.5 power-factor lagging @ 60 Hz. AC voltmeter - unity power factor.
- Response Time: 3 seconds (max.) for 2[1] ⁄2”, 3[1] ⁄2”, 4[1] ⁄2” size for microammeters; 2 seconds (max.) for all other DC ratings, and 2.5 seconds (max) for AC ratings.
- Overshoot: Maximum of 40% overshoot.
Buy the 260 100 FAFA YOKOGAWA DC Voltmeter | myMectronic
Purchase the YOKOGAWA 260 100 FAFA DC Voltmeter securely online and ensure reliable performance for your industrial needs.
