3M 3518 electronic connector
The 2500 Series offers a compact, low-profile connector solution suitable for surface-mount and through-hole applications. Featuring 0.100-inch pitch, these connectors come in straight and right-angle versions, designed for ease of assembly and reliable electrical performance. Made with glass-filled polyester insulators for high temperature resistance, they include optional features like retainer clips, polarizing keys, and high-temperature insulators for advanced soldering techniques. These connectors support up to 5A current per contact and comply with RoHS standards, ideal for space-constrained electronic modules demanding durability and versatility.
3M 3518 electronic connector Specifications:
- Insulator Material: Glass Filled Polyester (PBT or PCT for high temperature)
- Flammability: UL 94V-0
- Color: Gray (PBT) or Black (PCT)
- Contact Material: Copper Alloy
- Plating: Underplating 100” Nickel, Wiping Area Gold, Solder Tails Tin or Matte Tin
- Current Rating: 5.00A per contact, 3.00A for 6 contacts, 1.75A for all contacts
- Insulation Resistance: >1 x 10^10 Ohms at 500 V
- Withstanding Voltage: 1000 V at sea level
- Temperature Rating: -55°C to +105°C
- Process Rating: High Temp PCT insulator 260°C, PBT 191°C
- Moisture Sensitivity Level: 1
- Compliance: RoHS
Buy the 3M Series 2500 Connectors: High Temperature Low Profile Electronics Connectors
Upgrade your electronic assembly with 3M 2500 Series connectors, featuring low-profile design and optional high-temperature insulators. These connectors provide reliable electrical performance and quick assembly with straight and right-angle options, ideal for tight spaces in modern electronics. Manufactured with durable materials to withstand harsh environments, support high current loads, and meet RoHS standards. Perfect for applications requiring space-saving, resilient, and easy-to-maintain connectors, ensuring your projects achieve efficient, long-lasting connectivity.
Get 3M 3518 connectors today—built for precision, durability, and reliable electronic connections in space-constrained assemblies.
Frequently Asked Questions
Where can I buy 3M 3518?
You can click on the BUY or RFQ button to purchase 3518 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 3518?
You can download the 3518 datasheet or visit the 3M website for support.
Who is the manufacturer of 3518?
3M
