3M 9703 Electrically Conductive Adhesive Tape
Electrically conductive adhesive transfer tape with anisotropic electrical conductivity, designed for bonding EMI/RFI shields and gaskets to metal frames and enclosures. This pressure-sensitive acrylic adhesive features excellent tack properties, no thermal curing required, and is easy to handle. It is supplied on a silicone-treated, polycoated kraft paper release liner. The tape offers low contact resistance and effective EMI shielding performance. It can be applied as die-cut pieces or in roll form, adhering well to common substrates.
3M 9703 Electrically Conductive Adhesive Tape Specifications:
- Adhesive Type: Filled Acrylic Pressure Sensitive
- Approximate Thickness: Adhesive 2 mil (60 μm), Liner 4 mil (100 μm)
- Peel Adhesion to Stainless Steel: 29.02 g/in (180° peel, 1 hour @ 23°C), 32.02 g/in (24 hours)
- Temperature Performance Range: -40°C to +85°C in end-use applications
- Electrical Resistance: Contact Resistance less than 0.3 ohms, Insulation Resistance about 3.4 x 10^11 ohms/square
- Thermal Conductivity: 0.16-0.20 W/mK
- Available Widths: 0.25 to 12 inches, Lengths up to 108 yards
- Application Temperature: 15°C - 70°C, not below 10°C
- Storage Conditions: Shelf life of 24 months at 21°C and 50% relative humidity
- Application Method: Apply between 60°F - 158°F, use pressure of 15 psi or more, mechanical clamping recommended for stability
Buy the Buy 3M Electrically Conductive Adhesive Transfer Tape 9703 Part Number 9703 Online
Purchase 3M Electrically Conductive Adhesive Transfer Tape 9703 online to facilitate secure bonding of EMI/RFI shields and gaskets to various substrates. Designed for both flexible and rigid circuit interconnections, this tape provides excellent electrical conductivity, low contact resistance, and strong adhesion without thermal curing. Its anisotropic conductive properties ensure Z-axis connection while remaining insulating in the plane. Easy to cut, handle, and apply with mechanical clamping options, ensuring stable electrical performance across a temperature range of -40°C to 85°C. Ideal for electronics manufacturing and assembly.
Order your 3M Series9703 Electrically Conductive Adhesive Transfer Tape today and ensure reliable EMI/RFI shielding with easy-to-apply, high-performance bonding.
Frequently Asked Questions
Where can I buy 3M 9703?
You can click on the BUY or RFQ button to purchase 9703 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 9703?
You can download the 9703 datasheet or visit the 3M website for support.
Who is the manufacturer of 9703?
3M
