ABB 1SVR730830R0300 Voltage Monitoring Relay

ABB 1SVR730830R0300 Voltage Monitoring Relay Specifications:

• Extended Product Type: CM-EFS.2S
• Product ID: 1SVR730750R0400
• EAN: 4016779852128
• Catalog Description: CM-EFS.2S Voltage monitoring relay 2c/o, B-C=3-600VRMS, 24-240VAC/DC
• Long Description: The CM-EFS.2S is a single-functional voltage monitoring relay from the CM single-phase monitors range.
• Minimum Order Quantity: 1 piece
• Customs Tariff Number: 85364900
• Package Level 1 Width: 97 mm
• Package Level 1 Height: 109 mm
• Package Level 1 Length: 30 mm
• Package Level 1 Gross Weight: 0.179 kg
• Package Level 1 Units: 1piece
• Product Net Depth: 103.7 mm
• Product Net Height: 85.6 mm
• Product Net Weight: 0.157 kg
• Product Net Width: 22.5 mm
• Measuring Range: 3 ... 30 V, 6 ... 60 V, 30 ... 300 V, 60 ... 600 V
• Rated Control Supply Voltage (Us): 24 ... 240 V AC/DC
• Rated Frequency (f): 50 Hz, 60 Hz, DC Hz
• Output: 2 x 1 c/o or 1 x 2 c/o contacts; operating principle selectable
• Time Range: 0 s or 0.1-30 s tripping delay (ON or OFF)
• Terminal Type: Screw Terminals
• Rated Operational Current AC-12 (230 V): 4 A
• Rated Operational Current AC-15 (230 V): 3 A
• Rated Operational Current DC-12 (24 V): 4 A
• Rated Operational Current DC-13 (24 V): 2 A
• Minimum Switching Capacity: 24 V, 10 mA
• Rated Insulation Voltage (Ui): Measuring Circuit / Output Circuit 600 V, Output Circuit 1 / Output Circuit 2 250 V, Supply Circuit / Measuring Circuit 600 V, Supply Circuit / Output Circuit 250 V
• Rated Impulse Withstand Voltage (Uimp): Measuring Circuit / Output Circuit 6 kV, Output Circuit 1 / Output Circuit 2 4 kV, Supply Circuit / Measuring Circuit 6 kV, Supply Circuit / Output Circuit 4 kV
• Degree of Protection: Housing IP50, Terminals IP20
• Overvoltage Category: III
• Pollution Degree: 3
• Short-Circuit Protective Devices: Output Circuit NC - F Type Fuses 10 A, Output Circuit NO - F Type Fuses 10 A
• Electrical Durability: AC-12 100000 cycle
• Mechanical Durability: 30000000 cycle
• Connecting Capacity: Flexible with Ferrule 1x 0.5 ... 2.5 mm², Flexible with Ferrule 2x 0.5 ... 1.5 mm², Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm², Flexible 1x 0.5 ... 2.5 mm², Flexible 2x 0.5 ... 1.5 mm², Rigid 1x 0.5 ... 4 mm², Rigid 2x 0.5 ... 2.5 mm²
• Tightening Torque: 0.6 ... 0.8 N·m
• Wire Stripping Length: 8 mm
• Mounting Position: Any
• Mounting on DIN Rail: TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
• Standards: EN 50178, IEC/EN 60255-27, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 508, CAN/CSA C22.2 No.14
• Function: Over- and undervoltage monitoring
• Ambient Air Temperature (Operation): -20 ... +60 °C
• Ambient Air Temperature (Storage): -40 ... +85 °C
• Contact Rating UL/CSA: B300
• Connecting Capacity UL/CSA: Flexible 1x 18-14 AWG, Flexible 2x 18-16 AWG, Rigid 1x 20-12 AWG, Rigid 2x 20-14 AWG
• Tightening Torque UL/CSA: 7.08 in·lb
• Maximum Operating Voltage (UL/CSA): Output Circuit 300 V AC
• E-nummer: 3860615
• ETIM 4: EC001438 - Voltage monitoring relay
• ETIM 5: EC001438 - Voltage monitoring relay
• ETIM 6: EC001438 - Voltage monitoring relay
• eClass: 7.0 27371801
• Object Classification Code: B
