A Premier B2B Part Search
ABB ACSCPA Variable Frequency Drive
The ACS310 is a compact, versatile general purpose drive suitable for basic applications such as pumps, fans, and simple machinery. It features built-in pump and fan controls, energy-saving functions, robust design, and space-efficient mounting options. With preprogrammed macros and intuitive user interfaces, installation and commissioning are fast and easy. Key features include pump cleaning protection, Modbus communication, energy monitoring, multiple control macros, and remote monitoring capabilities through optional modules. Designed for variable torque loads, it offers reliable operation, reduces maintenance costs, and enhances energy efficiency in industrial applications.
ABB ACSCPA Variable Frequency Drive Specifications:
- Power Range: 0.37 to 22 kW (0.5 to 30 hp)
- Supply Voltage: 200-240 V (single-phase/four-wire), 380-480 V (three-phase), +10% tolerance
- Frequency: 48 to 63 Hz (50/60 Hz nominal)
- Continuous Output Current: From approximately 2 A at 0.37 kW to higher for larger models, with overload capability 10% for 1 minute every 10 minutes
- Control Method: Scalar U/f
- Analog Inputs: 2 universal analog signals, 0-10 V or -10 to 10 V; 4-20 mA signals
- Analog Output: 0-20 mA, load <500 ohms
- Digital Inputs: 5 digital inputs, 12-24 V DC, PNP/NPN, pulse train up to 16 kHz
- Relay Output: 1 transistor relay, 250 V AC/30 V DC, 0.5 A maximum
- Built-in Communication: Modbus EIA-485, Opt for external gateway for TCP/IP
- Protection Class: IP20 standard, optional NEMA 1 enclosure
- Ambient Temperature: -10°C to +50°C
- Enclosure Color: RAL 9002 or similar
- Compliance: Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/EC, RoHS
Buy the Buy ABB ACS310 Variable Frequency Drive Part Number ACSCPA Online
Order the ABB ACS310 drive online today and enjoy quick delivery, easy installation, and powerful features such as pump and fan control, energy monitoring, and multiple macros. With its compact design and intuitive interface, the ACS310 is perfect for industrial standards and variable torque applications. You can quickly set parameters with preconfigured macros, supporting efficient commissioning and operation. Optimize your equipment performance, save energy costs, and reduce maintenance efforts by choosing the reliable ABB ACS310 drive for your automation needs.
Buy ABB ACS310 drive now and experience unmatched reliability, energy efficiency, and easy control for your pumps, fans, and machinery.
Frequently Asked Questions
Where can I buy ABB ACSCPA?
You can click on the BUY or RFQ button to purchase ACSCPA from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part ACSCPA?
You can download the ACSCPA datasheet or visit the ABB website for support.
Who is the manufacturer of ACSCPA?
ABB
