ABB S202MD25 Miniature Circuit Breaker
System pro M compact S200M miniature circuit breakers are current limiting devices suitable for residential, commercial, and industrial applications. They feature two trip mechanisms: thermal for overload protection and electromagnetic for short circuit protection. With various characteristics, configurations, and breaking capacities, they ensure reliable performance. Their compact design allows for space-saving installation, with auxiliary contacts available for added functionality. Certified to IEC standards, these 2-pole breakers operate at rated currents up to 25A and voltage up to 440V AC, providing robust electrical protection in diverse environments.
ABB S202MD25 Miniature Circuit Breaker Specifications:
- Number of Poles: 2
- Tripping Characteristic: D
- Rated Current (In): 25A
- Rated Operational Voltage: 400 V AC
- Rated Short-Circuit Capacity: 10 kA at 230/400 V AC
- Rated Ultimate Short-Circuit Breaking Capacity: 25 kA at 230 V AC
- Rated Service Short-Circuit Breaking Capacity: 18.8 kA
- Energy Limiting Class: 3
- Overvoltage Category: 3
- Pollution Degree: 2
- Housing Material: RAL 7035, Insulation Group II
- Degree of Protection: IP40 in enclosure with cover
- Electrical Endurance: 20000 AC cycles
- Mechanical Endurance: 20000 cycles
- Terminal Type: Screw Terminals
- Tightening Torque: 2 Nm
- Mounting on DIN Rail: IEC 60715 TH35-7.5 or TH35-15
- Rated Frequency: 50/60 Hz
- Insulation Voltage: 440 V AC
- Operating Temperature: -25°C to +55°C
- RoHS Compliant: Yes
Buy the ABB S200M – Reliable Miniature Circuit Breaker for Industrial Applications
Enhance your electrical safety with this ABB miniature circuit breaker. Designed for residential, commercial, and industrial environments, it provides reliable overload and short-circuit protection. Easy to install on DIN rails, it features rated currents up to 25A and a breaking capacity of 10 kA at 230/400 V AC. Its compact design saves space while ensuring maximum protection. With certified standards, high endurance, and robust construction, this breaker ensures long-lasting performance. Buy online today for peace of mind and dependable electrical safety in your installations.
Order your ABB Series S200M 25A miniature circuit breaker today and give your projects the dependable safety and performance they deserve.
Frequently Asked Questions
Where can I buy ABB S202MD25?
You can click on the BUY or RFQ button to purchase S202MD25 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S202MD25?
You can download the S202MD25 datasheet or visit the ABB website for support.
Who is the manufacturer of S202MD25?
ABB
