ALPHA WIRE 3250VIOLET1000 Violet Hook Up Wire
The ALPHA WIRE 3250-VIOLET-1000 is a versatile hook-up wire designed for a wide range of industrial and commercial applications. Constructed with 24 AWG stranded copper conductors and a semi-rigid PVC insulation in a vibrant violet color, this wire offers excellent flexibility, durability, and electrical performance. It meets UL and CSA standards, ensuring reliability in various environments. The RoHS compliance indicates adherence to environmental regulations, making it suitable for modern electronic devices and systems. Available in both 1000ft and 100ft put-ups, this wire is ideal for both large-scale projects and smaller, specialized applications.
ALPHA WIRE 3250VIOLET1000 Violet Hook Up Wire Specifications:
- Component 1: 1 X 1 HOOKUP
- Conductor AWG: 24 (7/32)
- Insulation Wall: 0.010"
- Insulation Material: PVC, Semi Rigid
- Insulation Diameter: 0.044+/- 0.002
- Print: ALPHA WIRE E163869-* RU AWM STYLE 1061 80C 300V VW-1 24 AWG --- LLXXXX CSA AWM I A/B 80C 300 VOLTS FT1 ROHS
- Colors: WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN, ORANGE, SLATE, VIOLET, PINK
- UL Rating: AWM/STYLE 1061, 80°C / 300 VRMS, VW-1
- CSA Rating: AWM I A/B, 80°C / 300 VRMS, FT1
- Temperature Range: -10 to 80°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 3.5 Lbs, Maximum
- Voltage Rating: 300 VRMS
- Inductance: 0.05 µH/ft, Nominal
- Conductor DCR: 25 Ω/1000ft @20°C, Nominal
- 1000 FT Packaging: 6.5 x 2 x 1.9 inches
- 100 FT Packaging: 2.75 x 1 x 1.125 inches
