AMPHENOL INDUSTRIAL AHVB4KTA Industrial connector
The Amphenol industrial connectors feature a robust brush contact series designed for high vibration, chemical resistance, and high mating cycles up to 100,000. They support low insertion force, withstand temperatures up to 150°C, and provide IP67/IP69k sealing with optional backshells or heat shrink for harsh environments. Rated at 5 amps for signals and up to 16-18 AWG wire size, these connectors are ideal for industrial, medical, and rail applications requiring reliability, chemical imperviousness, and high vibration tolerance in compact sizes. They comply with SAE J2030 standards and offer easy mating with minimized mechanical effort.
AMPHENOL INDUSTRIAL AHVB4KTA Industrial connector Specifications:
- Current Rating: 5 Amps (1 Amp Hot Swap)
- Contact Size: 22
- Allowable Wire Size: 16-18 AWG
- Operating Temperature: -40°C to 150°C
- Contact Retention: 110N
- Mating Cycles: up to 100k
- Vibration: 53.79 grms
- Insulation Resistance: 50 GΩ (at 25°C)
- Dielectric Withstanding Voltage: 1960V AC (RMS)
- Operating Voltage: 1000 VDC (14 to 70 points)
- Moisture Resistance: IP67 (mated), optional IP69k with backshells or heat shrink
- Contact Plating: Gold
- Suitable for wire gauge: 16-18 AWG
- Temperature Range: -40°C to 150°C
- Designed to meet SAE J2030 standards
- Crimp tooling: Standard 38999 tools
- Removal tool: PN 10-708386-000
Buy the Buy Amphenol Industrial Part Number AHVB4KTA Online
Purchase the Amphenol AHVB Series industrial connector online today for high-performance, reliable connections in demanding environments. These connectors support up to 100,000 mating cycles and feature sealed IP67/IP69k protection, making them ideal for medical, rail, and industrial applications. Rated at 5 amps, they accommodate 16-18 AWG wires and withstand temperatures up to 150°C. Easy to install with minimal effort, ensuring secure and durable connections for critical systems. Order now for fast, secure delivery and enhance your project’s reliability.
Order your Amphenol Series AHVB4KTA industrial connector today and ensure reliable performance in harsh environments with high vibration tolerance and chemical resistance.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL AHVB4KTA?
You can click on the BUY or RFQ button to purchase AHVB4KTA from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part AHVB4KTA?
You can download the AHVB4KTA datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of AHVB4KTA?
AMPHENOL INDUSTRIAL
