AMPHENOL INDUSTRIAL C1073866608M3 Micro-B Connector
Amphenol's Micro-B Series Connectors are compact, lightweight, and high-performance cylindrical connectors designed for industrial and electronic environments. Constructed with an aluminum shell, they incorporate a robust triple bayonet coupling system for quick, secure mating and stamped & formed contacts for dependable electrical connections. Their high-density insert patterns, multiple mounting options, and excellent electromagnetic shielding make them suitable for harsh environments in automotive, automation, robotics, and telecommunications applications. They meet RoHS standards and offer corrosion resistance with Gray ZnNi plating, ensuring long-term durability and high reliability in demanding settings.
AMPHENOL INDUSTRIAL C1073866608M3 Micro-B Connector Specifications:
- Shell Material: Aluminum
- Insert Material: Plastic (PA66)
- Contact Material: Copper Alloy
- Contact Plating: Tin/Gold Plated
- Operating Temperature Range: -40°C to +125°C
- Ingress Protection: IP67 with backshell, IP54 with heat shrink
- Wave Ring: Stainless Steel
- EMI-Ring: Copper Alloy
- Retaining Ring: Stainless Steel
- Wave Ring: Stainless Steel
- Test Current: 3A (for #22D contact)
- Recommended Operating Voltage: AC 250V RMS
- Test Voltage: AC 500V RMS
- Insulation Resistance: 1000 MΩ at 500V
- Contact Resistance: Max 22 mΩ
- Mating Cycles: Up to 500 cycles
- Vibration: Compliant with IEC-364-28D
- Salt Spray Resistance: 500H with Gray ZnNi plating
- RoHS Compliant
Buy the Amphenol C1073866608M3 – Reliable Micro-B for Industrial Applications
Purchase the Amphenol Micro-B Connector Series C1073866608M3 online today to benefit from high durability, easy installation, and superior electromagnetic shielding. Perfect for industrial automation, robotics, automotive, and telecommunications applications, this small, lightweight connector provides reliable high-density connections. Featuring a rugged aluminum shell with a secure quarter-turn bayonet coupling, it guarantees quick mating and efficient performance in harsh environments. Order now and ensure your projects meet the highest standards of reliability, safety, and efficiency with this versatile, eco-friendly connector.
Order your Amphenol SeriesC1073866608M3 compact connector today and enjoy high reliability and quick mating in your industrial and automation projects.
