AMPHENOL INDUSTRIAL MS3102E181S Circular Connector
The MS3102E-18-1S is a durable circular connector designed for military and industrial applications. Featuring 10 solder cup contacts made from copper alloy with hard silver plating, it ensures reliable electrical connection even in harsh environments. The shell is crafted from aluminum alloy with olive drab chromate coating, providing excellent corrosion resistance. Neoprene grommets seal out moisture, while the threaded coupling guarantees secure assembly. With an operating voltage up to 3000VAC at sea level, this connector withstands extreme vibration, pressure, and temperature conditions, making it ideal for aerospace, military, and shipboard equipment requiring high durability and performance.
AMPHENOL INDUSTRIAL MS3102E181S Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate coating
- Contact Material: Copper alloy with hard silver plating
- Number of Contacts: 10
- Contact Type: Solder cup
- Contact Arrangement: 18-1
- Shell Size: 18
- Contact Resistance: Aan
- Operating Voltage: Up to 3000VAC at sea level
- Insulator Resistance: > 1000 MO per VG95319, VG95210 standards
- Test Voltage: 1600 Vrms
- Air and Creepage Path: 1.4 mm
- Ambient Temperature Range: -55°C to +125°C
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500
- Shell Plating: Olive drab chromate over cadmium
- Sealing: IP65 rated with Neoprene gromets
- Coupling Torque: Max 8 Nm closing, Min 0.58 Nm opening
- Contact Retention: 35N
- Wire Stripping: 6.2 mm
- Vibration Resistance: Suitable for harsh environments
- Durability: Able to withstand 3000VAC (RMS) at sea level
Buy the Cannon Series MIL-C-5015 Circular Connector: MS3102E-18-1S
Secure your equipment with the high-performance circular connector designed for extreme conditions. Featuring 10 solder cup contacts, corrosion-resistant aluminum shell, and moisture sealing, it ensures reliable electrical connections in military, aerospace, and shipboard applications. Easy to install with threaded coupling and polarization features, this robust connector withstands vibration, pressure, and temperature extremes. With a salt spray resistance of 500 hours and capable of handling up to 3000VAC at sea level, it’s a cost-effective solution for demanding environments requiring durability and dependable operation.
Buy Cannon MS3102E-18-1S now and experience unmatched reliability and performance in demanding military and industrial environments.
