AMPHENOL INDUSTRIAL SLPIPB50BSB3EH Electrical Connector
The SurLok Plus™ compression lugs from Amphenol Industrial are highly reliable and field-installable connectors designed for secure electrical terminations. These environmentally sealed lugs feature a compact design with quick-lock, press-to-release functionality, and incorporate the latest R4 RADSOK® technology for efficient mating. They are compatible with standard crimp, screw, and busbar termination methods, eliminating the need for special torque tools. Suitable for demanding applications such as electric and hybrid vehicles, battery management systems, energy storage, rail systems, automation, medical equipment, and heavy machinery.
AMPHENOL INDUSTRIAL SLPIPB50BSB3EH Electrical Connector Specifications:
- Flammability: UL 94 V-0
- Operating Temperature Range: -40°C to 125°C
- Current Rating: Up to 400A
- Voltage Rating: Up to 1000VAC/DC
- Connector Sizes: 5.7mm (120A), 8mm (200A), 10.3mm (350A)
- Sealing: IP67 sealed and non-sealed options
- Material: High-strength conductive components
- Contact Types: Crimp, screw, busbar
- Connector Types: Right-angle plug, straight plug, receptacle
- Keyway Angles: 60°, 90°, 120°, 150°, 180°, 270°
- Color Options: Orange, black, red
- Maximum Wire Gauge: Up to 95mm²
- Protection Features: EMI shielding, HVIL, touch-proof design
Buy the Amphenol Series SurLok Plus EMI Connector: SLPIPB50BSB3EH
Purchase the Amphenol SurLok Plus™ compression lugs online today to ensure secure, environmentally sealed electrical connections for your industrial, automotive, or energy storage projects. Designed with advanced R4 RADSOK® technology, these connectors offer quick-lock, press-to-release features for easy installation in demanding environments. Available in multiple sizes, configurations, and sealing options, they support high current up to 400A and operate reliably from -40°C to 125°C. Protect your systems with top-quality connectors tailored for heavy machinery, rail, medical, and automation industries—order now for fast delivery.
Buy Amphenol SurLok Plus connectors now and experience unmatched reliability and performance in demanding electrical environments.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL SLPIPB50BSB3EH?
You can click on the BUY or RFQ button to purchase SLPIPB50BSB3EH from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part SLPIPB50BSB3EH?
You can download the SLPIPB50BSB3EH datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of SLPIPB50BSB3EH?
AMPHENOL INDUSTRIAL
