Advantech Automation WISE2410MTB01 Wireless Condition Monitoring Sensor
The WISE-2410 is a compact LoRaWAN wireless condition monitoring sensor equipped with an ARM Cortex-M4 processor, 3-axis accelerometer, and temperature sensor. Designed for industrial applications, it supports star topology network communication with gateways, enabling real-time monitoring of equipment and environmental conditions. Its low-power design with a 2-year battery life, IP66 enclosure, and compatibility with WISE Studio utility make installation and maintenance straightforward. Suitable for HVAC, pumps, motors, and facility management, the WISE-2410 balances data transmission efficiently and is compliant with IS0 10816-3 standards, ensuring reliable operation in harsh environments.
Advantech Automation WISE2410MTB01 Wireless Condition Monitoring Sensor Specifications:
- Frequency Band US 902-928 MHz / EU 863-870 MHz / JP 920-928 MHz / TW 920-925 MHz
- LoRa/LoRaWAN star topology with gateway support up to 100 nodes
- Power Input: 3.6V AA Battery (not included)
- Battery Life: Up to 2 years with hourly data updates
- Operating Temperature: -20°C to 85°C
- Dimensions: 84.7 mm H x 48.3 mm D
- IP Class: IP66 for outdoor and harsh environments
- Operating Humidity: 40% to 95% RH
- Wireless Sensitivity: -148dB, Data Rate: 50 kbps at FSK, 5.47 kbps at SF7
- Sensor: 3-axis accelerometer with 10-1000Hz frequency range, 40-bit resolution, sensitivity 31.2mg/LSB
- Temperature Sensor Range: -20°C to 120°C, Accuracy: ±2°C at 85°C, ±5°C at 120°C
- Supported protocols: LoRaWAN, Modbus (via gateway), IP backbone
- Certifications: CE (RED), FCC, NCC, TELEC, VCCI, BSMI
Buy the Advantech Series WISE-2410 Wireless Condition Monitoring Sensor: WISE2410MTB01
Discover the advanced wireless condition monitoring sensor that combines LoRaWAN technology with integrated accelerometer and temperature sensors. With IP66 enclosure and a 2-year battery life, this sensor offers reliable, maintenance-free operation in harsh industrial environments. Easy to set up using WISE Studio utility, it supports star network topology for efficient communication with gateways and application servers. Ideal for HVAC, pumps, motors, and facility management, it ensures precise and real-time data collection to optimize your operations effortlessly.
Order your Advantech SeriesWISE-2410 wireless condition monitoring sensor today and ensure your industrial environment operates with dependable, real-time insights.
Frequently Asked Questions
Where can I buy Advantech Automation WISE2410MTB01?
You can click on the BUY or RFQ button to purchase WISE2410MTB01 from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part WISE2410MTB01?
You can download the WISE2410MTB01 datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of WISE2410MTB01?
Advantech Automation
