ALPHA WIRE 2463CSL005 Shielded Communication Cable
The 2463C SL005 is a 100-foot shielded communication and control cable featuring four 22 AWG stranded tinned copper conductors. It is insulated with polypropylene (PP), covered by an aluminum/polyester foil shield with a minimum 25% overlap for moderate electromagnetic interference (EMI) protection, and jacketed in slate PVC with a thickness of 0.51mm. Conductors are color-coded for easy identification. This high-performance cable complies with REACH regulations EC 1907/2006 and is suitable for various applications including audio, communications, networking, video, computer peripherals, automation, sensing, security, and industrial environments.
ALPHA WIRE 2463CSL005 Shielded Communication Cable Specifications:
- Number of Conductors: 4 x 22 AWG stranded tinned copper
- Insulation Material: Polypropylene (PP)
- Shield: Aluminum/Mylar foil with ≥25% overlap
- Jacket: Slate PVC, 0.51 mm thickness
- Color-Coding: Yes (white, black, green, yellow)
- Shield Coverage: ≥25%
- Outer Diameter: Not specified, typical jacket thickness 0.51 mm
- Temperature Range: -20 to 75°C
- Voltage Rating: 300 V
- Conductor Resistance: 16.2 O/1000ft at 20°C
- Inductance: 0.17 uH/ft
- Mutual Capacitance: 29 pF/ft at 1 kHz
- Ground Capacitance: 52 pF/ft at 1 kHz
- DCR per 1000ft: Conductor 16.2 Ohms, Shield 12 Ohms
- Maximum Length Options: 100 ft, 250 ft, 1000 ft
Buy the Alpha Wire 2463C U– Reliable Shielded Communication Cable for Industrial Applications
Purchase the Alpha Wire 2463C shielded communication cable online today for reliable performance in industrial automation, networking, audio, and video applications. This high-quality cable features four 22 AWG stranded tinned copper conductors with polypropylene insulation, an aluminum/mylar foil shield for EMI protection, and a resilient slate PVC jacket. Designed to meet various industry standards and regulations including REACH, it ensures durability and consistent signal integrity. Ideal for professionals seeking high-performance cables for demanding industrial environments, automation, security, and multimedia deployments. Order now for quick delivery and expert support.
Get Alpha Wire 2463C today—built for precision, shielding, and durable performance in industrial and communication systems.
Frequently Asked Questions
Where can I buy ALPHA WIRE 2463CSL005?
You can click on the BUY or RFQ button to purchase 2463CSL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 2463CSL005?
You can download the 2463CSL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 2463CSL005?
ALPHA WIRE
