AMPHENOL COMMUNICATIONS SOLUTIONS 69168114HLF Wire-to-Board Connector System
The PV wire-to-board connector system offers high reliability and durability, featuring dual-metal receptacle terminals that maintain contact pressure through 1000 mating cycles. It connects discrete wires to printed circuit boards with industry-standard 0.025 inch square posts, suitable for automation, instrumentation, medical, industrial, automotive, and communication applications. The system includes shrouded headers, polarized MINI-LATCH housings, and offers customizable spring pressures for various insertion forces. Made from high-quality materials, it supports voltages up to 1000V RMS and operates efficiently within -40°C to +105°C temperature range, ensuring secure and gas-tight connections for demanding environments.
AMPHENOL COMMUNICATIONS SOLUTIONS 69168114HLF Wire-to-Board Connector System Specifications:
- Contact Material: Brass body, beryllium copper spring, phosphor bronze headers
- Plating: Gold or lead-free pure tin over nickel
- Housing Material: Modified polyphenylene oxide UL94V-0 (Mini-LATCH), glass-filled nylon UL94V-0 (headers)
- Current Rating: 3.0A per circuit with 32 AWG wire
- Voltage Rating: 1000V RMS
- Insulation Resistance: >10000MQ (wire connector), >5000MQ (header)
- Contact Resistance: <2mQ
- Temperature Range: -40°C to +105°C
- Durability: 1000 mating cycles
- Wire Range: Up to 1.52mm diameter
- Mating Force: 75g to 450g depending on spring force
- Un-mating Force: 175g to 450g depending on spring force
- Connectivity: Single and double row configurations, polarized housings
Buy the FCI PV Wire-to-Board Connector – Reliable Connection for Industrial Applications
Enhance your electronic assemblies with FCI's PV wire-to-board connector system, featuring high reliability, gas-tight gas, and durable design. This versatile system is perfect for industrial, automotive, medical, and communication applications, supporting voltages up to 1000V RMS and enduring 1000 mating cycles. Compact, polarized, and available in multiple configurations, it ensures secure connections in demanding environments. Easy to install using specialized tooling, it provides excellent electrical performance with low contact resistance. Choose FCI for quality, safety, and performance in your electronic projects.
Buy FCI PV wire-to-board connectors now and ensure secure, high-quality connections in industrial, automotive, and communication systems.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 69168114HLF?
You can click on the BUY or RFQ button to purchase 69168114HLF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 69168114HLF?
You can download the 69168114HLF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 69168114HLF?
AMPHENOL COMMUNICATIONS SOLUTIONS
