AMPHENOL COMMUNICATIONS SOLUTIONS HM2R10PA5100AALF Backplane Connector
The Millipacs 2mm Hard Metric series right-angle receptacle connectors are modular interconnection components designed for high-density PCB and cable-to-board applications, ensuring reliable electrical connections in communications, industrial, and medical systems. Constructed with high-temperature polymers and gold/palladium plated copper alloy contacts, they support currents up to 1.5A and voltage of 750 Vrms. These connectors offer excellent mechanical durability, optional shielding, and scalable modular lengths, meeting IEC standards for versatile, high-performance signal, power, and coaxial circuit integration in demanding environments.
AMPHENOL COMMUNICATIONS SOLUTIONS HM2R10PA5100AALF Backplane Connector Specifications:
- Insulator Material: High-Temperature Polymer
- Contact Material: Copper Alloy
- Contact Plating: Gold/Palladium Nickel on Mating Areas, Tin over Nickel on Press-fit Areas
- Operating Current: 1.5A at 20°C, 1.0A at 70°C
- Test Voltage: 750 Vrms
- Contact Resistance: 20 mΩ Max
- Insulation Resistance: 10^9 Ω Min
- Mating Force: 0.75 N Max per contact
- Withdrawal Force: 0.15 N Min per contact
- Temperature Range: -55°C to +125°C
- Mechanical Tolerance: Longitudinal +2.0mm, Transversal +2.5mm, Inclination +2.0°
- Standards: IEC 917, IEC 61076-4-101, Telcordia GR-1217-CORE, UL, CSA
- Packaging: Tray
- Application: Communications, Data, Medical, Industrial & Instrumentation sectors
Buy the Millipacs 2mm Hard Metric – Reliable Backplane Connectors for Industrial Applications
Secure your project with the Millipacs 2mm Hard Metric backplane connector. Designed for high-density, scalable, and reliable PCB and cable connections, this connector meets IEC standards and is suitable for demanding communication, medical, and industrial applications. Made from high-temperature polymer with gold/palladium plated copper alloy contacts, it supports currents up to 1.5A and voltages of 750 Vrms. The modular design ensures easy customization, efficient routing, and durable performance, making it an ideal choice for mission-critical electronic systems.
Order your Millipacs series HM2R10PA5100AALF backplane connector today and ensure robust, high-performance connections for your industrial systems.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS HM2R10PA5100AALF?
You can click on the BUY or RFQ button to purchase HM2R10PA5100AALF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part HM2R10PA5100AALF?
You can download the HM2R10PA5100AALF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of HM2R10PA5100AALF?
AMPHENOL COMMUNICATIONS SOLUTIONS
