AMPHENOL COMMUNICATIONS SOLUTIONS L117DBFRA25S D-Sub Connector
These D-Sub connectors feature stamped and formed contacts, suitable for compact modem peripheral equipment and industrial applications. Made with nickel-plated steel shells and glass-filled thermoplastic insulators, they support current ratings of 5A and operate within -40°C to +125°C. Designed for standard 1.27mm flat ribbon cable connections, these connectors are compatible with all standard D-Sub hoods. They offer robust mechanical and electrical performance, including withstand voltage of 1000V AC, low contact resistance, and various mounting options including front screwlock and rear inserts. Ideal for telecom, industrial, and equipment assembly projects requiring reliable RF and data connections.
AMPHENOL COMMUNICATIONS SOLUTIONS L117DBFRA25S D-Sub Connector Specifications:
- Shell Material: Steel with nickel plating
- Insulator Material: Glass-filled thermoplastic, UL 94V-0
- Pin Contact Material: Brass with gold and nickel plating
- Socket Contact Material: Phosphor bronze with gold and nickel plating
- Rated Current: 5A
- Voltage Rating: 250V AC/rms 60Hz
- Withstanding Voltage: 1000V AC/rms 60Hz
- Insulation Resistance: 1000MQ
- Contact Resistance: 20mQ max
- Operating Temperature: -40°C to +125°C
- Mechanical Force (Insertion): Max 0.54kg (1.19Ib)
- Mechanical Force (Withdrawal): Min 0.06kg (0.13Ib)
- Mating and Unmating Force: Varies by size, e.g., 3.05mm for 9 contacts
- Dimensions: Based on contact size, e.g., 30.84mm length for 9 contacts; detailed dimensions provided
- Plating Thickness: 0.4um (15μ") gold or 0.76um (30μ") gold over tin
- Mounting Options: Front screwlock with M3 or 4-40; rear insert M3 or 4-40; support for hand termination tool
- Certifications: RoHS compliant, MIL C24308 connectors
Buy the Amphenol L117DBFRA25S – Reliable D-Sub Connectors for Industrial Applications
Upgrade your industrial, telecom, or equipment assembly with the durable and reliable D-Sub connectors. Featuring nickel-plated shells and gold-plated contacts, these connectors provide excellent electrical performance, low contact resistance, and high voltage withstand ability. Designed for standard flat ribbon cables, they support various mounting options including screwlocks and rear inserts for versatile application. Whether for precise data, RF, or power connections, these connectors ensure lasting performance in harsh environments, making your projects more reliable and efficient. Purchase online now to streamline your assembly process.
Order your Amphenol SeriesL117DBFRA25S D-Sub connector today and enhance your equipment with dependable, high-quality connections suitable for industrial and telecom projects.
