AMPHENOL COMMUNICATIONS SOLUTIONS L177SDE09SOL2 D-Sub Connector
The Amphenol SD series consists of precision-formed D-sub connectors available in standard and high-density configurations, designed for PCB mounting with closed-entry contact cavities. Crafted with durable materials such as thermoplastic insulators, brass, and phosphor bronze contacts with gold and nickel plating, these connectors support current ratings of 3A to 5A and voltage ratings up to 250V AC. They withstand temperatures from -55°C to +125°C, resist salt spray, and feature reliable contact resistance under rigorous climatic and mechanical conditions, ensuring high performance in industrial, telecom, and standard applications.
AMPHENOL COMMUNICATIONS SOLUTIONS L177SDE09SOL2 D-Sub Connector Specifications:
- Shell Material: Steel
- Insulator Material: Glass-filled thermoplastic, UL 94V-0
- Pin Contact Material: Brass with gold and nickel plating
- Socket Contact Material: Phosphor bronze with gold and nickel plating
- Current Rating: Standard Density 5A, High Density 3A
- Voltage Rating: 250V AC/ rms 50Hz, 1000V AC/ rms 50Hz for one minute
- Insulation Resistance: 1000 MΩ at 500V DC
- Contact Resistance: Max 20 mΩ
- Operating Temperature: -55°C to +125°C
- Salt Spray Resistance: 24 hours
- Mechanical: Contact insertion force 0.02-0.06 kg, withdrawal force 0.44-1.19 lb
- Overall Dimensions: Vary by contact count, approx. 12.55 mm to 69.32 mm in length
- Plating Thickness: Gold flash 0.381 µm (151µ”) or 0.76 µm (30µ”), Nickel 2.54 µm (100µ”), Tinned shell options available
- Mounting Options: Panel mounting, threaded rear insert, retention clips
- RoHS Compliant: Yes
Buy the Amphenol Series SD D-Sub Connector: L177SDE09SOL2
Purchase the Amphenol SD series D-Sub connector online today and enjoy high reliability with precision-formed contacts, durable materials, and robust construction. Designed for industrial and telecom applications, these connectors feature sealed entry cavities, withstand harsh environments, and offer excellent electrical performance. With a variety of mounting options and high-quality plating, they ensure secure connections for your critical projects. Order now to benefit from quick delivery, competitive pricing, and the assurance of Amphenol's trusted expertise for all your connector needs.
Get Amphenol SD series high-density PCB mount connectors today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS L177SDE09SOL2?
You can click on the BUY or RFQ button to purchase L177SDE09SOL2 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part L177SDE09SOL2?
You can download the L177SDE09SOL2 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of L177SDE09SOL2?
AMPHENOL COMMUNICATIONS SOLUTIONS
