Amphenol-Communications-Solutions L17DTZF25RGL717DB25PST D-Sub Connector Kit
The product is a screw-type D-Sub connector kit designed for reliable industrial and electronic applications. It features zinc, nickel-plated D-Sub hoods, and steel shells with gold-plated brass contacts. Suitable for AWG 18 wire sizes, it offers excellent EMI shielding, re-openable design with spring-clip mounted jackscrews, and robust insulation. Operating temperatures range from -45°C to +105°C for the hood and -55°C to +85°C for the connector. It supports voltages over 1000V RMS, has a current rating of 7.5A, and is available in 9, 15, and 25 positions.
Amphenol-Communications-Solutions L17DTZF25RGL717DB25PST D-Sub Connector Kit Specifications:
- Material: Zinc, Nickel Plated D-Sub Hood
- Operating Temperature: -45°C to +105°C (Hood), -55°C to +85°C (Connector)
- Cable Entry: Top Entry
- Cable O.D - Standard: 9-way up to 6.5mm with grommet, 15-way up to 6.5mm, 25-way up to 8.0mm with grommet
- Shell: Steel, Tin Plated
- Contact Material: Machined Brass pins
- Contact Plating: Gold flash over Nickel
- Insulator: Glass filled TP, UL94 V-0
- Wire Size: AWG 18
- Withstanding Voltage: >1000V RMS to 50Hz for 1 min
- Current Rating: 7.5A
- Insulator Resistance: >5000 MΩ minimum
- Features: Re-openable, Excellent EMI Shielding, Spring-Clip mounted Jackscrews
- Size Variants: 9, 15, 25 positions
- Dimensions (for reference): 9-way: 31.6mm x 39.5mm x 15.2mm, 15-way: 40mm x 41mm x 15.2mm, 25-way: 53.7mm x 47.5mm x 15.2mm
Buy the Umax L17DTZF25 – Reliable D-Sub Connector for Industrial Applications
Get the Umax L17DTZF25 screw-type D-Sub connector kit online today for reliable, high-performance connectivity in industrial and electronic applications. Featuring zinc, nickel-plated hoods, steel shells, and gold-plated brass contacts, this connector offers excellent EMI shielding, robust insulation, and re-openable design for easy maintenance. Supports AWG 18 wires, withstands over 1000V RMS, withstanding temperatures from -45°C to +105°C (hood) and -55°C to +85°C (connector). Available in 9, 15, and 25 positions for versatile use in demanding environments.
Order your Umax L17DTZF25 series connector today and ensure dependable, EMI-shielded connections for your industrial electronics projects.
Frequently Asked Questions
Where can I buy Amphenol-Communications-Solutions L17DTZF25RGL717DB25PST?
You can click on the BUY or RFQ button to purchase L17DTZF25RGL717DB25PST from an authorized Amphenol-Communications-Solutions distributor.
How do I troubleshoot issues or seek technical support for part L17DTZF25RGL717DB25PST?
You can download the L17DTZF25RGL717DB25PST datasheet or visit the Amphenol-Communications-Solutions website for support.
Who is the manufacturer of L17DTZF25RGL717DB25PST?
Amphenol-Communications-Solutions
