Amphenol-Communications-Solutions L17DTZF37LJSRGL77HDC62S High Density D-Sub Connector
The high-density D-Sub connector kit features zinc, nickel-plated metal shells capable of operating between -45°C and +105°C. It includes sizes HD15, HD26, HD44, and HD62, with cable entry at the top and thumbscrews standardized to UNC 4-40. The solder cup contacts are made from copper alloy with gold flash over nickel plating, and insulators are glass-filled thermoplastic UL94 V-0 rated. These connectors provide excellent EMI shielding, withstand voltage over 1000V, and support current up to 3A, making them reliable for high-performance electronic and industrial applications.
Amphenol-Communications-Solutions L17DTZF37LJSRGL77HDC62S High Density D-Sub Connector Specifications:
- Material: Zinc, Nickel Plated
- Operating Temperature: -45°C to +105°C
- Cable Entry: Top Entry
- Thumbscrews: UNC 4-40
- Cable O.D - Standard: 9-Way up to 6.5mm with grommet, 15-Way up to 6.5mm, 25-Way up to 8.0mm, 37-Way up to 9.0mm
- Insulator: Glass filled thermoplastic, UL94 V-0
- Shell: Steel, Tin Plated
- Contact pins: Copper Alloy, gold flash over nickel
- Operating Temperature: -55°C to +85°C
- Withstanding voltage: >1000V RMS to 50Hz for 1 minute
- Current Rating: 3A
- Insulator resistance: >5000MO min.
- Available sizes: HD15, HD26, HD44, HD62
- EMI Shielding: Excellent
- Re-openable: Yes
- Dim A: 31.6mm (HD15), 40.0mm (HD26), 53.7mm (HD44), 70.2mm (HD62)
- Dim B: 39.5mm (HD15), 41.0mm (HD26), 47.5mm (HD44), 48.0mm (HD62)
- Dim C: 15.2mm (all sizes)
Buy the Amphenol Series High Density D-Sub Connector: L17DTZF37LJSRGL77HDC62S
Purchase the high-density D-Sub connector kit online today and enjoy superior EMI shielding, reliable solder cup contacts, and excellent temperature resistance. Designed for industrial and electronic applications, these connectors support multiple sizes including HD15, HD26, HD44, and HD62, with top entry cable access and durable steel shells. Suitable for high-vibration environments, they offer withstanding voltage over 1000V and support current up to 3A, ensuring your connections remain stable and efficient in demanding conditions.
Buy Amphenol high density D-Sub connector kit now and experience unmatched reliability and performance in high-pin-count electronic connections.
