AMPHENOL COMMUNICATIONS SOLUTIONS L717DB25PST1 Dsub Connector
The Screw Termination D’Sub series by Amphenol offers reliable, compact connectors designed for field applications, featuring easy wiring with a standard screwdriver. Constructed with steel shells, glass-filled thermoplastic insulators, and machined brass or bronze contacts with full gold plating, they support up to 7.5A and 300V RMS at 50Hz, with high insulation resistance. Suitable for control of speed variators, infrastructure fluid control, and building automation, these connectors are compatible with standard hoods and accessories, ensuring durability in harsh environments from -55°C to +85°C.
AMPHENOL COMMUNICATIONS SOLUTIONS L717DB25PST1 Dsub Connector Specifications:
- Shell Material: Steel, Tin plated
- Insulator Material: Glass filled thermoplastic, UL 94V-0
- Contacts: Machined brass for plug (full gold), machined bronze for socket (full gold)
- Current Rating: 7.5 A maximum
- Voltage Rating: 300 V RMS at 50 Hz, 1000 V RMS at 50 Hz
- Insulation Resistance: > 5000 MQ at 500 V DC
- Contact Resistance: <5 mΩ
- Operating Temperature Range: -55°C to +85°C, peak at 125°C
- Mechanical: Mating Cycles: 100 (Class I) or 500 (Class II), Screw Torque: 0.05 mN
- Cable Compatibility: Solid or stranded, max AWG 18 (0.75 mm)
- Cable Stripping Length: 3 mm
- Climatic Tests: Damp heat 21 days, Salt spray 48 hours
Buy the Amphenol 717D – Reliable Signal Connectors for Industrial Applications
Purchase the Amphenol 717D D-Sub connectors online now for high performance, easy field wiring, and durable construction suitable for control panels, infrastructure, and automation systems. These compact connectors feature screw termination, full gold contacts, and are designed for harsh environments, operating comfortably from -55°C to +85°C. Supported by UL and other certifications, they ensure safety and reliability. Ideal for control of speed variators, building automation, and infrastructure fluid control, order today for guaranteed quality and quick delivery.
Order your Amphenol 717D Series screw termination connectors today and ensure reliable, durable connections for industrial and automation projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS L717DB25PST1?
You can click on the BUY or RFQ button to purchase L717DB25PST1 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part L717DB25PST1?
You can download the L717DB25PST1 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of L717DB25PST1?
AMPHENOL COMMUNICATIONS SOLUTIONS
