AMPHENOL COMMUNICATIONS SOLUTIONS L77TSBH25SOL2C309 PCB Connector
The Amphenol SD series offers precision-formed contacts and closed entry contact cavities, ensuring high reliability and quality for industrial, telecom, and standard connections. Designed for economical PCB mounting, it supports standard and high-density configurations with various contact counts. Materials include UL 94V-0 thermoplastic shells, gold-plated brass, and phosphor bronze contacts, providing excellent electrical performance and thermal stability. With robust construction, these connectors withstand -55°C to +125°C and 24-hour salt spray, making them ideal for demanding industrial applications requiring durable and reliable PCB connections.
AMPHENOL COMMUNICATIONS SOLUTIONS L77TSBH25SOL2C309 PCB Connector Specifications:
- Shell Material: Steel
- Insulator Material: Glass-filled thermoplastic, UL 94V-0
- Pin Contact Material: Brass with gold in mating area, tin over nickel on termination
- Socket Contact Material: Phosphor bronze with gold in mating area, tin over nickel on termination
- Current Rating: Standard Density 5A, High Density 3A
- Voltage Rating: 250V AC/rms, 1000V AC/rms for one-minute withstand voltage
- Insulation Resistance: 1000MΩ at 500V DC
- Contact Resistance: 20mΩ max
- Operating Temperature: -55°C to +125°C
- Salt Spray Resistance: 24 hours
- Mechanical: Contact insertion force SD 0.06kg to 0.54kg, HD 0.02kg to 0.52kg
- Dimensions: Length varies with contact count, standard density overall dimension A+0.38mm, B+0.13mm
- Plating: Gold flash (+0.381um gold), or +0.76um gold for durability
- Certifications: Complies with MIL C24308, NFC 93425-HES
Buy the Amphenol L77TSBH25SOL2C309 – Reliable PCB Connector for Industrial Applications
Order the Amphenol PCB connector series, including high-density and standard options, designed for demanding industrial, telecom, and standard electronic applications. These connectors feature precision-formed contacts, UL 94V-0 thermoplastic shells, and gold or tin plating to ensure excellent electrical performance, thermal stability, and long-term durability. Suitable for PCB mounting in harsh environments, they withstand extreme temperatures and salt spray with ease. Purchase online now to benefit from high-quality, reliable connections that meet industry standards for safety and efficiency, ensuring optimal system performance.
Get Amphenol L77TSBH25SOL2C309 today—built for precision and long-lasting durability in PCB connections.
