AMPHENOL COMMUNICATIONS SOLUTIONS LD09P24A4GX00LF D-Subminiature Connector
The LD09P24A4GX00LF is an economical D-Subminiature connector designed for less demanding applications in industrial, consumer, and data communication sectors. It features a robust D-shaped shell, gold flash-plated contacts, and a durable plastic insulator capable of withstanding temperatures from -55°C to +105°C. Suitable for PCB mounting with straight or angle terminations, this connector supports up to 50 mating cycles and provides reliable electrical performance with rated voltages up to 250V and currents of 5A, ensuring proper signal integrity in various equipment.
AMPHENOL COMMUNICATIONS SOLUTIONS LD09P24A4GX00LF D-Subminiature Connector Specifications:
- Insulation Resistance: >5000MQ
- Insulator: Glass filled Thermoplastic (UL94V-0)
- Dielectric Strength: 1000V RMS
- Contact Material: Copper Alloy with Gold Flash plating
- Shell Material: Steel with Nickel/Tin plating
- Operating Temperature Range: -55°C to +105°C
- Current Rating: 5A
- Rated Voltage: 250V
- Contact Resistance: <25mΩ
- Durability: 50 mating cycles
- Retention against Torque: 0.5Nm
Buy the FCI LD09P24A4G – Reliable D-Subminiature Connector for Industrial Applications
Enhance your projects with the FCI LD09P24A4G D-Subminiature connector, a cost-effective and reliable solution for low-demand applications. Featuring gold flash-plated contacts, robust steel shells, and thermoplastic insulators, this connector ensures optimal electrical performance from -55°C to +105°C. Suitable for PCB mounting with straight or angle terminations, it supports up to 50 mating cycles, rated at 250V and 5A, making it ideal for consumer electronics, industrial equipment, and energy meters. Order online today for superior quality and performance.
Order your FCI Series LD09P24A4G D-Subminiature connector today and equip your industrial systems with a dependable, high-performance interface.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS LD09P24A4GX00LF?
You can click on the BUY or RFQ button to purchase LD09P24A4GX00LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part LD09P24A4GX00LF?
You can download the LD09P24A4GX00LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of LD09P24A4GX00LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
