AMPHENOL COMMUNICATIONS SOLUTIONS RJE881881400 Modular Jack
The modular jack features an 8-position, 8-contact shielded design without tabs or LEDs, made from high-temperature thermoplastic with UL 94V-0 flammability rating. It has phosphor bronze contacts with selective gold plating on mating surfaces, ensuring reliable connections. The stainless steel shield is tin-dipped for durability, with a tail length of approximately 2.70 mm and optional gold plating thicknesses of 50 or 5 microinches. Designed for wave soldering at 260°C for up to 5 seconds, it includes plated holes and recommended PCB layout specifications. Suitable for networking and communication systems requiring durable and compliant modular connectors.
AMPHENOL COMMUNICATIONS SOLUTIONS RJE881881400 Modular Jack Specifications:
- Housing Material: High temperature thermoplastic, UL 94V-0 flammability rating
- Contact Material: Phosphor bronze with selective gold plating
- Shield: Stainless steel with tin dip
- Tail Length: Approximately 2.70 mm
- Gold Plating Options: 5 or 50 microinches
- Wave Soldering Temperature: 260°C for 5 seconds maximum
- Number of Positions: 8
- Number of Contacts: 8
- Unplated Holes: 2 required
- Plated Holes: 2 required
- Housing Color: Black
- Dimensions and layout: Refer to AMPHENOL specifications and recommended PCB layout with tolerances ±0.05 mm
- Compliance: RoHS
- Connection Type: Modular jack for networking applications
Buy the Amphenol Series Modular Jack: RJE88-188-1X0X
Order the Amphenol RJE88-188-1X0X modular jack online today for your networking and communication systems. This 8-position, 8-contact shielded connector features high-temperature thermoplastic housing, gold-plated contacts for optimal conductivity, and a stainless steel shield with tin dip. Designed for wave soldering at 260°C for up to 5 seconds, it provides precise dimensions and reliable performance. Perfect for high-quality, RoHS-compliant network installations, ensuring durability and consistent connectivity across your applications. Purchase now for exceptional engineering and dependable operation.
Get Amphenol RJE88-188-1X0X today—built for reliable connections and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS RJE881881400?
You can click on the BUY or RFQ button to purchase RJE881881400 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part RJE881881400?
You can download the RJE881881400 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of RJE881881400?
AMPHENOL COMMUNICATIONS SOLUTIONS
