AMPHENOL COMMUNICATIONS SOLUTIONS T812120A101CEU Industrial Socket
The TS812 WC socket is a 2.54mm pitch connector with 64 positions, constructed from glass-reinforced thermoplastic PBT with UL 94V-0 rating. The contact material is phosphor bronze, with optional gold or tin plating for durability and reliable electrical connections. It is rated for 500 VDC, 3A current per contact, and withstands temperatures from -40°C to +105°C. Suitable for industrial applications requiring high insulation and resistance, this socket features a strain relief option for enhanced support and durability during use.
AMPHENOL COMMUNICATIONS SOLUTIONS T812120A101CEU Industrial Socket Specifications:
- Pitch: 2.54mm
- Positions: 64
- Material (Insulator): Glass-reinforced thermoplastic, UL 94V-0, PBT
- Contact Material: Phosphor Bronze
- Plating Options: Flash Gold or Selective Gold, 100u" Tin on termination
- Voltage Rating: 500 VDC, 250 VAC
- Current Rating: 3A per contact
- Contact Resistance: 20 mΩ max at 1A
- Insulation Resistance: 1000 MΩ min
- Dielectric Withstanding Voltage: 500 VAC RMS for one minute
- Operating Temperature: -40°C to +105°C
- Environmental Resistance: Suitable for industrial environments with high resilience
- Body Material: Glass-reinforced thermoplastic, UL 94V-0
- Plating Thickness: 50u" nickel under-plate, optional gold plating
- Strain Relief: Available
Buy the IDC Socket 64 Positions Reliable Connector for Industrial Applications
Enhance your electronics with our reliable 2.54mm pitch industrial socket featuring 64 positions, gold or tin plating, and a high voltage rating of 500V. Designed for robustness, it withstands temperatures from -40°C to +105°C and provides excellent electrical performance. This socket is ideal for industrial automation, control panels, and high-density electronic assemblies, offering secure strain relief options and durable construction. Purchase online now to ensure your project benefits from top-quality, dependable connections used in demanding industrial environments.
Order your high-durability IDC Socket 64 Positions today and ensure reliable connections in your industrial and electronic projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS T812120A101CEU?
You can click on the BUY or RFQ button to purchase T812120A101CEU from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part T812120A101CEU?
You can download the T812120A101CEU datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of T812120A101CEU?
AMPHENOL COMMUNICATIONS SOLUTIONS
