AMPHENOL LTW DC05BMMAQL8LPP waterproof connector
This waterproof connector features a durable nylon+GF body with gold-plated copper pins, silicone O-Ring and Seal for reliable sealing. UL 94V-0 rated and RoHS compliant, it supports electrical ratings up to 300Vac/Vde with high insulation resistance. Designed for harsh environments, it withstands temperatures from -40°C to 105°C and resists salt spray corrosion for up to 1000 hours. Suitable for data and power applications, it offers easy field installation with a compact design and mechanical durability for over 1000 cycles.
AMPHENOL LTW DC05BMMAQL8LPP waterproof connector Specifications:
- Material: Nylon+GF body, Copper Alloy pins, Silicone O-Ring
- UL Rated: UL 94V-0, RoHS Compliant
- Electrical Ratings: 300Vac/Vde, Contact Resistance: 10m Max.
- Insulation Resistance: 100MΩ Min., Dielectric Withstand Voltage: 1,600 Vac.
- Mechanical Durability: 1000 Cycles, Tensile Strength: 10 kgf.
- Wire Range: 22AWG~20AWG (5A), 14AWG~12AWG (20A)
- Wire Insulation OD: 1.9mm Max. (5A), 4.3mm Max. (20A)
- Clamp Ring Torque: 6~8 kgf-cm, Seal Nut Torque: 6~8 kgf-cm
- Waterproof Rating: IP68 (Mated, 24 Hours), Temperature Range: -40°C to 105°C
- Salt Spray Resistance: 1000 Hours, Suitable for Data & Power Applications
Buy the Amphenol DC05BMMAQL8LPP – Reliable Waterproof Connector for Industrial Applications
Purchase the waterproof connector today online for dependable performance in challenging conditions. Designed with high-quality nylon and copper parts, it ensures durability and reliable electrical connections for data or power needs. The product features silicone sealing rings for IP68 waterproof rating, supporting temperatures from -40°C to 105°C, and resists corrosion from salt spray for up to 1000 hours. Easy to install in the field, this connector is ideal for industrial, automation, and harsh environment applications, ensuring safety and longevity.
Get Amphenol DC05BMMAQL8LPP today—built for precision, challenging environments, and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL LTW DC05BMMAQL8LPP?
You can click on the BUY or RFQ button to purchase DC05BMMAQL8LPP from an authorized AMPHENOL LTW distributor.
How do I troubleshoot issues or seek technical support for part DC05BMMAQL8LPP?
You can download the DC05BMMAQL8LPP datasheet or visit the AMPHENOL LTW website for support.
Who is the manufacturer of DC05BMMAQL8LPP?
AMPHENOL LTW
