AMPHENOL RF 095850221012 Waterproof RF Connector
Amphenol RF offers waterproof, IP67-rated TNC and RP-TNC connectors with threaded coupling for secure, reliable connections in outdoor, industrial, and military applications. These connectors feature durable construction, tamper resistance, and various configurations such as straight, right-angle, and bulkhead mounts, suitable for antennas, wireless systems, and broadband installations. Certified for environmental challenges, these connectors ensure high performance across broad frequency ranges up to 11 GHz, with high durability for repeated mating cycles. Designed with brass, copper, PTFE insulators, and silicone gaskets, they meet RoHS standards, providing excellent electrical performance and environmental resilience.
AMPHENOL RF 095850221012 Waterproof RF Connector Specifications:
- Impedance: 50 ohms
- Frequency Range: DC - 11 GHz
- Return Loss: 3 (-18 dB) Max.
- Dielectric Withstanding Voltage: 1500 VRMS Max.
- Insulation Resistance: 5000 MΩ Min.
- Contact Resistance: Center contact 1.5 mΩ Max., Outer contact 0.2 mΩ Max.
- Coupling Style: Threaded
- Mating Cycles: 500 Min.
- Temperature Range: -65°C to +165°C
- RoHS: Compliant with Exemption 6C
- Body and Outer Contacts: Brass
- Male Contact: Brass Beryllium Copper
- Female Contact: Beryllium Copper
- Crimp Ferrule: Brass
- Insulator: PTFE
- Gasket: Silicone
Buy the Buy Amphenol RF Waterproof TNC Part Number 095850221012 Online
Enhance your projects with the durable, waterproof TNC connector from Amphenol RF, part number 095850221012. Designed for outdoor and industrial environments, it features IP67 sealing, threaded coupling, and tamper resistance. Suitable for antennas, wireless systems, and broadband applications, this connector withstands harsh conditions with an operating temperature range from -65°C to +165°C. Its high-quality materials and eco-friendly RoHS compliance ensure long-lasting electrical performance and environmental resilience. Order online now for fast, reliable delivery and upgrade your system's connectivity.
Order your Amphenol RF Waterproof TNC Part Number 095850221012 today and ensure your outdoor and industrial systems have the reliable, secure connectors they need.
Frequently Asked Questions
Where can I buy AMPHENOL RF 095850221012?
You can click on the BUY or RFQ button to purchase 095850221012 from an authorized AMPHENOL RF distributor.
How do I troubleshoot issues or seek technical support for part 095850221012?
You can download the 095850221012 datasheet or visit the AMPHENOL RF website for support.
Who is the manufacturer of 095850221012?
AMPHENOL RF
