Amphenol Sine Systems AT0412PDBL05 12 Pin Circular Connector
The Amphenol AT04-12PD-BL05 is a robust, circular connector designed for reliable performance in harsh industrial environments. Its thermoplastic housing and silicone rubber seal provide excellent protection against moisture, dust, and other contaminants, meeting IP69K and IP68 standards. This connector is commonly used in applications such as automotive, heavy machinery, and outdoor equipment where a secure and sealed connection is critical. It is compatible with AT06-12SX* plug series and offers enhanced keying for secure mating. Its design ensures durability and long-term reliability in challenging conditions.
Amphenol Sine Systems AT0412PDBL05 12 Pin Circular Connector Specifications:
- Current Rating: 13 Amps
- Operating Temperature: -55°C to +125°C
- Dielectric Withstanding Voltage: Less than 2 milliamps @ 1500 Volts AC
- Insulation Resistance: 1000 Megohms Min @ 25°C
- Moisture Resistance: IP69K & IP68
- Mating Cycle Durability: 100 Cycles
- Material (Housing): Thermoplastic
- Material (Seal): Silicone Rubber
- Mating Part: AT06-12SX* Plug
Buy the AT04-12PD-BL05 Amphenol Sine Systems 12 Pin Circular Connector | myMectronic
Purchase the Amphenol AT04-12PD-BL05 securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Amphenol Sine Systems AT0412PDBL05?
You can click on the BUY or RFQ button to purchase AT0412PDBL05 from an authorized Amphenol Sine Systems distributor.
How do I troubleshoot issues or seek technical support for part AT0412PDBL05?
You can download the AT0412PDBL05 datasheet or visit the Amphenol Sine Systems website for support.
Who is the manufacturer of AT0412PDBL05?
Amphenol Sine Systems
