Amphenol Sine Systems RTS6BS14N19P03 19 Position Circular Connector
The Amphenol Sine Systems RTS6BS14N19P03 is a high-performance circular connector designed for demanding environments. Constructed with a thermoplastic housing (UL94 V-0), it provides excellent flame retardancy and durability. The connector's IP67 and IP69K ratings ensure protection against dust and water ingress, making it ideal for applications in automotive, industrial automation, and heavy machinery. It supports a rated current of 5A and a rated voltage of 250V (AC/DC), with a dielectric withstanding voltage suitable for many applications. The connector is RoHS compliant and designed for 500 mating cycles, ensuring long-term reliability.
Amphenol Sine Systems RTS6BS14N19P03 19 Position Circular Connector Specifications:
- Material_Shell: Thermoplastic, UL94 V-0
- Material_Insert: Thermoplastic, UL94 V-0
- Material_CouplingNut: Thermoplastic, UL94 V-0
- Material_O_Ring: NBR or Silicone Rubber
- Material_Washer: Silicone Rubber
- Material_BackShell: Thermoplastic, UL94 V-0
- Material_ClampNut: Thermoplastic, UL94 V-0
- Material_ClampRing: Thermoplastic, UL94 V-0
- Material_CableSeal: EPDM
- Rated_Current: 5A (MAX)
- Rated_Voltage: 250V (AC/DC)
- Operating_Temperature: -40°C ~ +105°C / -40°C ~ +125°C
- Dielectric_Withstanding_Voltage: Less than 2 Milliamps Current Leakage @ 2000 Volts AC
- Insulation_Resistance: 5000 Megohms Min
- IP_Class: IP67 and IP69K (Mated Condition)
- Mating_Cycles_Durability: 500 Cycles Min
- Suitable_Contacts: 20# Contact
- Cable_OD_Range_1: 6.0-12.0MM
- Cable_OD_Range_2: 9.0-14.0MM
- Dimension_A: 12.3MM / 14.3MM
