Anderson Power Products 269G3LPBK Blindmate Connector
The Anderson Power Products Multi Axial Rotational Connector MARC features eight Powerpole circuits embedded in a blindmate housing. Designed for blind mating from two rotating axes or in a straight line, this connector has a two-row, horizontally oriented layout with industry-leading flat wiping contacts. Rated for 29 amps per circuit, it offers configuration options with eight standard-length contacts or six standard-length and two pre-mate, multi-purpose contacts that can serve as ground, power, or signal connections. The rugged construction includes a chemically resistant PBT plastic dielectric, and the connector is UL listed with a rated lifespan of up to 10,000 mating cycles.
Anderson Power Products 269G3LPBK Blindmate Connector Specifications:
- Number of Circuits: 8
- Rated Current per Circuit: 29 Amps
- Rated Voltage: 600V AC/DC (UL Listed)
- Dielectric Material: PBT plastic, chemically resistant
- Contact Type: Flat wiping contacts
- Mating Cycles: Up to 10,000 cycles
- Temperature Range: -40°C to +125°C
- Connection Options: 6 standard-length and 2 pre-mate contacts (multi-purpose)
- Housing: Blindmate, two-row, horizontally oriented
- Ground and Signal Compatibility: Yes
- Rated for blind mating from 2 rotating axes or straight on
Buy the Buy Anderson Power Products Connector Part Number 269G3LPBK Online
Order the Anderson Power Products MARC connector online today and enjoy the benefits of a rugged, high-current rated connector designed for demanding industrial environments. With up to 10,000 mating cycles and flexible configuration options including multi-purpose contacts, this connector ensures long-lasting performance and easy installation. Perfect for blind mating from two rotating axes or a straight line, it offers excellent reliability, chemical resistance, and safety features, making it an essential component for complex electrical systems. Buy now to enhance your operational efficiency!
Buy Anderson Power Products MARC connector now and experience unmatched durability, high current capacity, and reliable performance for industrial applications.
Frequently Asked Questions
Where can I buy Anderson Power Products 269G3LPBK?
You can click on the BUY or RFQ button to purchase 269G3LPBK from an authorized Anderson Power Products distributor.
How do I troubleshoot issues or seek technical support for part 269G3LPBK?
You can download the 269G3LPBK datasheet or visit the Anderson Power Products website for support.
Who is the manufacturer of 269G3LPBK?
Anderson Power Products
