Apem AC3559 4x4 Matrix Keypad
The APEM AC3559 is a robust 4x4 matrix keypad designed for various industrial applications requiring reliable key input. It incorporates a silver perimeter embossing on a black background, enhancing visual clarity and tactile feedback. The keypad boasts a 30V contact voltage rating, a 100mA contact current rating, and a travel distance of 0.80 to 0.90 mm. Its mechanical design includes a 1.20 mm polymer tactile dome and a 0.25 mm upper circuit embossing, ensuring a responsive and durable user experience. The operating temperature range of -30 to +55 degrees Celsius makes it suitable for demanding environments. Supplied with two inserts featuring black graphics on a silver background, the AC3559 offers versatility and customization options.
Apem AC3559 4x4 Matrix Keypad Specifications:
- Contact Force: 400 grams
- Travel: 0.80 to 0.90 mm
- Tactile Dome: 1.20 mm Polymer
- Upper Circuit Embossing: 0.25 mm
- Contact Voltage Rating: 30V (dc)
- Contact Current Rating: 100mA
- Insulation Resistance: >100 Mohms
- Dielectric Strength: 250 V rms
- Capacitance: 10 pF typ.
- Contact Bounce: < 10 msec. typ.
- Operating Temperature: -30 to +55 C
- Storage Temperature: -40 to +60 C
- Overall Thickness: 1.50 mm
- Pin Pitch: 2.54 mm
- Connector Type: Female
- Keypad Matrix: 4x4
- Insert Graphics: Black graphics on a silver background
Buy the AC3559 APEM 4x4 Matrix Keypad | myMectronic
Purchase the APEM AC3559 4x4 Matrix Keypad securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Apem AC3559?
You can click on the BUY or RFQ button to purchase AC3559 from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part AC3559?
You can download the AC3559 datasheet or visit the Apem website for support.
Who is the manufacturer of AC3559?
Apem
