Apem QH22L28RC RGB Indicator Light
The QH22L RGB LED indicator offers vibrant multi-color illumination suitable for industrial control panels and emergency stop switches. Featuring a 22mm panel cutout, sealed to IP67 for durability against dust and water ingress, it supports operation within -30°C to +70°C. The LED assembly is designed with RGB, dual, and single-color options, featuring 12 LEDs on a PC board. Powered by 12 to 24 VDC, it includes 200mm UL1061 wire terminations, optimized for reliable long-life performance with a 50,000-hour life expectancy. Ideal for automation, machinery, and safety applications requiring clear visual signaling.
Apem QH22L28RC RGB Indicator Light Specifications:
- Panel Seal: IP67 to EN60529 : 1992
- Operating Temperature Range: -30°C to +70°C
- Max Reverse Voltage: 5 VDC
- Life Expectancy: 50,000 Hours
- LED Types: Single, dual, RGB with 12 LEDs
- Body Material: PC
- Lens Material: PC
- Voltage Range: 12 VDC to 24 VDC
- Operating Current: 42 mA to 20 mA
- Wire Terminations: 200 mm, UL1061, 26 AWG
- Mounting: 22 mm panel cutout
- Sealing: IP67
- Environmental Compatibility: EMC immunity EN61000-4-3, emissions EN61000-6-4, electrostatic discharge EN61000-4-2
- Weight and dimensions vary with model, typical diameter 22 mm, depth approximately 30mm
Buy the APEM Series QH QH22L RGB Indicator: QH22L28RC
Purchase the APEM QH22L28RC RGB indicator light online today for reliable, waterproof signaling in industrial control panels. Designed to withstand harsh environments with IP67 sealing, it features vivid multi-color illumination, long-lasting LED life, and easy mounting in 22mm panel cutouts. Ideal for automation, safety, and machinery applications, this indicator operates on 12 to 24 VDC with quick wiring via 200mm UL1061 cables. Enhance your control systems by choosing APEM’s durable, high-performance RGB indicator lights for clear, bright signaling that lasts.
Get APEM QH22L28RC today—built for precision, durability, and reliable visual signaling in industrial environments.
Frequently Asked Questions
Where can I buy Apem QH22L28RC?
You can click on the BUY or RFQ button to purchase QH22L28RC from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part QH22L28RC?
You can download the QH22L28RC datasheet or visit the Apem website for support.
Who is the manufacturer of QH22L28RC?
Apem
