BROADCOM HCPL7720000E High-Speed CMOS Optocoupler
The HCPL-7720 optocoupler series utilizes CMOS technology for high-speed digital communication and isolation. Available in 8-pin DIP and SO-8 packages, these devices deliver fast propagation delays of 40 ns, low pulse-width distortion, and high common-mode rejection. Designed for reliable fieldbus, data transmission, and microprocessor interface applications, they feature robust safety, including UL recognition and IEC/EN certifications. Their dual-inverting architecture ensures stable operation even if power is lost, making them ideal for industrial automation, network isolation, and safety-critical circuits with excellent electrical safety and insulation properties.
BROADCOM HCPL7720000E High-Speed CMOS Optocoupler Specifications:
- Package: 8-pin DIP, SO-8 surface mount options
- Propagation Delay: 40 ns
- Pulse-Width Distortion: 3 to 6 ns
- Data Rate: 25 MBd
- Input Voltage: 0.5 V to 12 V
- Output Voltage: 0 to 5 V
- Maximum Output Current: 9 mA
- Solder Temperature: 260°C for 10 sec.
- Thermal Resistance Junction-to-Case: 140-160 °C/W
- Isolation Voltage: 3750 Vrms (UL), 3750 Vrms (CSA)
- Input-Output Voltage: 6000 V peak (option 060), 3750 Vrms (base)
- Temperature Range: -40°C to +85°C
- Power Dissipation: 150 mW
- Compliance: UL 1577, IEC/EN 60747-5-2, RoHS
Buy the Buy Avago HCPL-7720 Series High-Speed Optocoupler Part Number HCPL772000E Online
Purchase the Avago HCPL-7720 series CMOS optocoupler online now and benefit from fast propagation delay of 40 ns, high data rate of 25 MBd, and robust electrical safety features. Perfect for industrial automation, fieldbus networks, and microprocessor interfaces, these devices offer excellent noise immunity and reliable galvanic isolation within a compact package. With UL recognition and RoHS compliance, safe, efficient, and high-speed data communication is easily achieved. Order today for quick delivery and seamless integration into your systems.
Order your Avago HCPL-7720 series high-speed CMOS optocoupler today and enhance your industrial automation and data transmission systems with reliable, fast isolation.
Frequently Asked Questions
Where can I buy BROADCOM HCPL7720000E?
You can click on the BUY or RFQ button to purchase HCPL7720000E from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HCPL7720000E?
You can download the HCPL7720000E datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HCPL7720000E?
BROADCOM
