BROADCOM HFBR1528Z Fiber Optic Transmitter
The HFBR-1528Z is a high-performance, 10 Mbaud versatile fiber optic transmitter designed for reliable data transmission with enhanced voltage isolation, improved EMI/RFI immunity, and data security. It features a horizontal mount configuration with a 660 nm LED and internally optimized optics for use with 1 mm diameter plastic optical fiber. The module accounts for connector interface losses, simplifying optical calculations for typical applications. It is compatible with standard TTL circuitry and offers a peak supply current of 6 mA, an interlocking feature, high noise immunity, and flame-retardant construction. Operating within a temperature range of 0 to 70°C, this transmitter is suitable for telecommunications, networking, fiber optics, and automotive applications.
BROADCOM HFBR1528Z Fiber Optic Transmitter Specifications:
- Wavelength: 660 nm
- Peak Output Power: +0.5 to 60 dBm (at 60 mA drive current)
- Drive Current: 60 mA (max), 20 mA (typical)
- Power Supply Voltage: 4.75 V to 5.25 V
- Operating Temperature: 0°C to +70°C
- Peak Forward Input Current: 90 mA
- Soldering Temperature: +260°C for 10 seconds
- Optical Rise Time: 13 ns
- Optical Fall Time: 10 ns
- Wavelength Tolerance: ±12 nm
- Thermal Resistance, Junction to Case: 140 °C/W
- RoHS compliance: Yes
- Fiber Compatibility: Plastic Optical Fiber 1 mm, Hard Clad Silica 200 um
- Data Rate: DC to 10 MBd, NRZ
Buy the Buy Avago HFBR-1528Z Part Number HFBR1528Z Online
Enhance your optical communication systems with the HFBR-1528Z fiber optic transmitter. Designed for reliable data transfer at 10 MBd, it features high output power, low power consumption, and excellent noise immunity. Its compatibility with 1 mm plastic optical fiber and HCS® makes it versatile for telecom, factory automation, and automotive applications. Easy to integrate with TTL logic outputs, it supports operation from 0°C to 70°C, ensuring stable performance in demanding environments. Purchase online today and upgrade your fiber optic solutions effortlessly.
Buy Avago HFBR-1528Z now and experience unmatched reliability and high-speed data transmission for fiber optic networks and industrial control.
Frequently Asked Questions
Where can I buy BROADCOM HFBR1528Z?
You can click on the BUY or RFQ button to purchase HFBR1528Z from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HFBR1528Z?
You can download the HFBR1528Z datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HFBR1528Z?
BROADCOM
