BROADCOM HLMPY701G0000 Amber LED Lamp
The HLMP-Y701G0000 is a high-efficiency, bright amber LED lamp in the T-1 (3 mm) package, ideal for indicator and backlighting applications. It features high luminous intensity output, low power consumption, and reliable construction. Suitable for mounting on PCB or panel, it offers versatile options for front panels, light pipes, switches, and general indicator functions. The LED operates at a maximum junction temperature of 110°C, with forward voltage around 2.0-2.2V at 20mA, ensuring long-lasting performance and excellent visibility in various industrial lighting and signaling solutions.
BROADCOM HLMPY701G0000 Amber LED Lamp Specifications:
- Package Type: T-1 (3 mm)
- Color: Amber
- Luminous Intensity Min: 140 Iv (med) at 20 mA
- Peak Wavelength: 595 nm
- Dominant Wavelength: 582-597 nm
- Spectrum Half Width: 15 nm
- Forward Voltage: 2.0-2.2 V at 20 mA
- Peak Wavelength: 595 nm
- Reverse Voltage: 5 V
- Maximum DC Forward Current: 20 mA
- Peak Forward Current: 60 mA (1/10 Duty Cycle)
- Junction Temperature: 110°C
- Power Dissipation: 48 mW
- Storage and Operating Temperature Range: -40 to +100°C
- Material: Epoxy encapsulated, leaded package
- Lead Spacing: 2.54 mm
- RoHS compliant
- Soldering Conditions: 250°C max, dwell time 3 seconds
- Dimensions: Length 24.0 mm min, lead spacing 2.54 mm
Buy the Avago HLMP-Y701G0000 – Reliable Amber LED for Industrial Applications
Purchase the Avago HLMP-Y701G0000 amber LED lamp online today for high luminous intensity and energy efficiency. Perfect for indicator lights, backlighting, and industrial signaling, this 3 mm T-1 package ensures reliable performance with a lifespan of long-lasting operation. Its easy mounting options and RoHS compliance make it ideal for various electronic applications. Order now and benefit from fast delivery, competitive pricing, and the assurance of authentic, high-quality LED components designed to meet stringent industry standards for visibility and durability.
Get Avago HLMP-Y701G0000 today—built for bright illumination and long-lasting durability in indicator and backlighting solutions.
Frequently Asked Questions
Where can I buy BROADCOM HLMPY701G0000?
You can click on the BUY or RFQ button to purchase HLMPY701G0000 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HLMPY701G0000?
You can download the HLMPY701G0000 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HLMPY701G0000?
BROADCOM
