BROADCOM HSMUA100R00J1 Surface Mount LED Indicator
This high-brightness surface mount LED indicator features a compact PLCC-2 packaging, designed for harsh environments like automotive interior and industrial signage. It offers a 120° wide viewing angle and excellent reliability under various environmental conditions. Suitable for panel, push button, or backlighting applications, it is compatible with IR reflow and wave soldering processes. It emits in multiple colors including red, orange, amber, yellow, green, and blue, with high luminous efficacy, making it ideal for signage, panel illumination, and general backlighting in diverse electronic applications.
BROADCOM HSMUA100R00J1 Surface Mount LED Indicator Specifications:
- Package Type: PLCC-2 surface mount
- Viewing Angle: 120°
- Color Options: Red, Orange, Amber, Yellow, Green, Blue
- Emission Technologies: GaP, AlGaAs, AllnGaP, InGaN
- Forward Voltage: 1.9V to 3.4V depending on color and technology
- Current Rating: 20mA (operating), Peak 100mA
- DC Forward Current: 30mA recommended
- Power Dissipation: 48mW to 114mW
- Operating Temperature: -55°C to +100°C
- Storage Temperature: -55°C to +100°C
- Viewing Angle: 120°
- Package Dimensions: Length approx. 2.84mm, Width approx. 3.20mm
- Compatibility: IR reflow and wave soldering
- RoHS Compliant: Yes
- Lead-Free: Yes
Buy the Buy Avago Technologies HSMUA100R00J1 Part Number High Brightness Surface Mount LED Indicator Online
Purchase the Avago Technologies high-brightness surface mount LED indicator HSMUA100R00J1 online today. Designed for harsh environments, it offers a 120° wide viewing angle and is compatible with both IR reflow and wave soldering. Ideal for automotive interior, signage, and general backlighting applications, this component features multiple color options including red, orange, amber, yellow, green, and blue. Its high reliability, RoHS compliance, and optimal specifications ensure excellent performance and long-lasting illumination in diverse electronic systems and industrial equipment.
Order your Avago Technologies HSMUA100R00J1 surface mount LED today and upgrade your electronic projects with reliable, high-brightness illumination.
Frequently Asked Questions
Where can I buy BROADCOM HSMUA100R00J1?
You can click on the BUY or RFQ button to purchase HSMUA100R00J1 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HSMUA100R00J1?
You can download the HSMUA100R00J1 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HSMUA100R00J1?
BROADCOM
