BELDEN 73609W0081000 Multi-Conductor Cable
The 73609W Multi-Conductor cable is a high-quality, unshielded 600V cable designed for light to moderate flexing applications. Featuring 16 AWG stranded bare copper conductors (26x30), it includes nine conductors plus a ground wire, all with PVC insulation and an oil-resistant PVC jacket. It offers excellent flexibility with a flex life up to 1 million cycles, making it ideal for industrial automation, machinery, and control applications. The cable's overall diameter is 0.509 inches, and it meets UL, CSA, and EU standards for safety and environmental compliance. Its durable construction ensures reliable electrical performance in demanding environments.
BELDEN 73609W0081000 Multi-Conductor Cable Specifications:
- Conductor AWG: 16
- Number of Conductors: 9
- Ground Wire AWG: 16
- Ground Wire Stranding: 26x30
- Ground Wire Material: Bare Copper
- Insulation Material: PVC
- Outer Jacket Material: PVC
- Overall Diameter: 0.509 in.
- Flex Life: Up to 1 million cycles
- Storage Temperature Range: -40°C to +90°C
- Installation Temperature Range: -8°C to +90°C
- Bulk Cable Weight: 354 lbs/1000 ft.
- Max. Pulling Tension: 184 lbs
- Min. Bend Radius: 2.5 in.
- UL Specification: UL Style 2587 (600 V, 90°C)
- CSA Specification: 600 V
- RoHS Compliant: Yes
- Flame Test: CSA FT
- Suitable for Burial: Yes
Buy the Belden 73609W – Reliable Multi-Conductor for Industrial Applications
Purchase the Belden 73609W multi-conductor cable online today to experience premium quality wiring for industrial automation and control systems. This unshielded 600V cable features 16 AWG stranded bare copper conductors with PVC insulation and oil-resistant jacket, designed for light to moderate flexing applications. Its flexible, durable construction supports up to 1 million flex cycles, making it perfect for demanding environments. Buy online now to ensure your projects benefit from reliable electrical performance, ease of installation, and compliance with safety standards.
Order your Belden 73609W multi-conductor cable today and ensure reliable, flexible wiring for your industrial automation projects.
Frequently Asked Questions
Where can I buy BELDEN 73609W0081000?
You can click on the BUY or RFQ button to purchase 73609W0081000 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 73609W0081000?
You can download the 73609W0081000 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 73609W0081000?
BELDEN
