BELDEN 9L28014008H300 Ribbon Cable
Belden's .050 inch pitch gray ribbon cable is designed for general electronic interconnect applications, providing reliable mass-termination to IDC connectors. It features 4 conductors, insulation made of PVC, and offers a temperature range from -40°C to +105°C. With a nominal width of 70 +/- .008 inches and a thickness of 0.035 +/- .003 inches, this unshielded cable meets UL, CSA, and EU standards for safety and environmental compliance. Suitable for versatile electronic circuitry, it ensures durability, high insulation resistance, and flame resistance in demanding environments.
BELDEN 9L28014008H300 Ribbon Cable Specifications:
- Number of Conductors: 4
- Conductor Pitch: .050 +/- .002 inches
- Conductor Outside Center to Outside Center Spacing: 65 +/- .008 inches
- Insulation Material: PVC
- Insulation Resistance: > 10,000 Megaohms
- Outer Shield: Unshielded
- Overall Width: 70 +/- .008 inches
- Overall Thickness: 0.035 +/- .003 inches
- Operating Temperature Range: -40°C to +105°C
- Weight: 16 lbs per 1000 ft
- UL Rating: 105°C, 300 V RMS, VW-1
- CSA Specification: AWM IA 105°C 300 VFT1
- Flame Test: UL VW-1, CSA FT1
- Conductor Resistance: 68.2 Ohms/1000 ft max
- Dielectric Withstand Voltage: 2,000 V RMS
- Polarity Identification: Red stripe on conductor #1
- Compliance: RoHS, WEEE, ELV, BFR, Prop 65
Buy the Belden 9L28014008H3 – Reliable Electronic Ribbon Cable for Industrial Applications
Order the Belden 9L28014008H3 ribbon cable online today to ensure high-quality, durable electrical connections for your electronic projects. This versatile cable features a .050 inch pitch, 4 conductors, PVC insulation, and UL/CSA safety standards. Its wide temperature range from -40°C to +105°C suits various industrial settings, while its flame-resistant properties guarantee safety. With a weight of 16 lbs per 1000 ft and easy mass termination to IDC connectors, this cable delivers reliable performance and compliance. Buy now for fast delivery and peace of mind.
Buy Belden 9L28014008H3 ribbon cable now and experience reliable electronic interconnect performance in industrial and electronic environments.
Frequently Asked Questions
Where can I buy BELDEN 9L28014008H300?
You can click on the BUY or RFQ button to purchase 9L28014008H300 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 9L28014008H300?
You can download the 9L28014008H300 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 9L28014008H300?
BELDEN
