BELDEN C601100007 Ethernet Patch Cord
The Belden CAT6+ Modular Cord is a high-performance patch cable designed for reliable data transmission in industrial, commercial, and network applications. This 7 ft. blue cable features bonded-pair construction, solid 24 AWG conductors, and complies with TIA Category 6 standards, ensuring excellent performance for 1000BASE-T and other Gigabit Ethernet networks. It is rated for indoor use with UL riser certification, rated for temperatures from -10°C to +60°C, and features durable Polycarbonate plugs with elastomer boots. Suitable for use in IBDN systems, data centers, and networking setups requiring high-speed, stable connectivity and easy installation. Compliant with RoHS and IEC standards, it promises long-lasting durability and easy integration.
BELDEN C601100007 Ethernet Patch Cord Specifications:
- Cable Length: 7 ft. (2.1 m)
- Color: Blue
- Conductor Material: 24 AWG solid copper
- Insulation Material: Polyolefin
- Outer Jacket Material: PVC
- Outer Diameter: 0.228 inches
- Connectors: RJ45 with polycarbonate plugs and elastomer boots
- Wiring Scheme: T568A/B, T568A/B
- Temperature Range (Operating): -10°C to +60°C
- Installation Temperature: -10°C to +46°C
- Max. Pull Tension: 25 lbs.
- Min. Bend Radius: 1.04 inches
- UL Rating: Riser (UL 1666)
- Standards: TIA 568-C.2, ISO/IEC 11801, IEC 60603-7
- RoHS Compliant: Yes
- Electrical Resistance (Max Contact Resistance): 20 m-Ohm
- Dielectric Strength: 1,000 V RMS @ 60 Hz for 1 minute
- Insulation Resistance: 500 M-Ohm Minimum
Buy the Belden C601100007 – Reliable Ethernet Patch Cord for Industrial Applications
Purchase the Belden C601100007 Ethernet Patch Cord online today for reliable, high-performance network connectivity. Designed with bonded-pair construction, solid 24 AWG conductors, and UL riser certification, this 7 ft. blue cable ensures excellent data transmission for industrial setups, data centers, and enterprise networks. Its durable polycarbonate connectors and elastomer boots offer long-lasting performance with easy installation. Compliant with RoHS and IEC standards, this patch cord provides stability, flexibility, and high-speed Ethernet capabilities, making it ideal for demanding network environments requiring consistent, fast, and reliable connections.
Get Belden C601100007 today—built for high-speed, stable networking in industrial and commercial environments.
Frequently Asked Questions
Where can I buy BELDEN C601100007?
You can click on the BUY or RFQ button to purchase C601100007 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part C601100007?
You can download the C601100007 datasheet or visit the BELDEN website for support.
Who is the manufacturer of C601100007?
BELDEN
