Bourns 4310R101102 Resistor Array
This Bourns thick film molded SIP resistor array features 10 pins in a bussed configuration, offering a resistance value of 1 kilo-ohm. It is designed for high reliability in electronic applications, with features including low profile, RoHS compliance, and compatibility with automatic insertion equipment. The resistor array withstands environmental stresses such as moisture and thermal shock, conforming to UL94V-0 flammability standards. It supports a maximum operating voltage of 100 V and operates across temperatures from -55°C to +125°C, making it suitable for complex circuit designs requiring multiple resistors in a compact package.
Bourns 4310R101102 Resistor Array Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: +100 ppm/°C (50 Ω to 2.2 MΩ), +250 ppm/°C (below 50 Ω and above 2.2 MΩ)
- Operating Temperature: -55°C to +125°C
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Lead Solderability: Meets MIL-STD-202 Method 208
- Flammability: UL 94V-0
- Lead Frame Material: Copper, solder coated
- Body Material: Novolac epoxy
- Power Rating at 70°C: 0.30 watt per resistor
- Environmental Testing: Moisture resistance, thermal shock, terminal strength, resistance to soldering
- Physical Configuration: 10-pin molded SIP, bussed configuration
- Termination: RoHS compliant tin-plated, optional tin/lead-plated
- Model Number: 4310R101102
- Resistance Value: 1 kilo-ohm
Buy the Bourns Series 4300R Resistor Array: 1kΩ SIP Package
Purchase the Bourns 4300R Series resistor array online today and enjoy reliable performance in high-density electronic designs. This 10-pin molded SIP package offers a resistance value of 1 kilo-ohm, with features including RoHS compliance, high environmental resistance, and compatibility with automatic insertion. Designed for durability, it withstands temperature extremes from -55°C to +125°C and supports a maximum voltage of 100 V. Ideal for applications requiring multiple resistors in a compact, reliable package, ensuring your circuits operate efficiently and consistently.
Get Bourns 4300R Series 4310R101102 resistor array today—built for precision, high-density circuits, and long-lasting durability.
Frequently Asked Questions
Where can I buy Bourns 4310R101102?
You can click on the BUY or RFQ button to purchase 4310R101102 from an authorized Bourns distributor.
How do I troubleshoot issues or seek technical support for part 4310R101102?
You can download the 4310R101102 datasheet or visit the Bourns website for support.
Who is the manufacturer of 4310R101102?
Bourns
