Bourns SRP04202R2K Power Inductor
The SRP0420 series shielded power inductors feature a metal alloy powder core with high saturation current and low buzz noise, suitable for power supply filtering and energy storage in electronic circuits. These inductors are RoHS compliant and halogen free, ensuring environmental safety. They operate efficiently within a temperature range of -40°C to +125°C, with rated voltages of 50V and inductance values from 0.47μH to 10μH. Optimized for high frequency applications, these compact inductors are ideal for industrial electronics and power management systems.
Bourns SRP04202R2K Power Inductor Specifications:
- Inductance range: 0.47μH to 10μH
- Tolerance: ±10%
- Operating temperature: -40°C to +125°C
- Rated voltage: 50V
- Core material: Metal alloy powder
- Shielded construction for noise reduction
- RoHS compliant and halogen free
- Maximum DC resistance (DCR): varies with model, e.g., 8.9 mΩ for R47K
- Saturation current: up to 18.0A for certain models
- Peak temperature: 260°C during soldering, max 30 sec
Buy the Bourns SRP0420 R2K – Reliable Power Inductor for Industrial Applications
Enhance your electronic designs with the Bourns SRP0420 series power inductors, engineered for high saturation current and noise reduction. These shielded, RoHS-compliant inductors are perfect for industrial applications, power supplies, and energy storage systems. Operating efficiently from -40°C to +125°C, and capable of withstanding soldering peak temperatures of 260°C, they offer reliable performance in demanding environments. Invest in these compact and environmentally friendly inductors online today and ensure optimal efficiency and durability for your electronics projects.
Order your Bourns SeriesSRP0420 R2K shielded power inductor today and enhance your power management projects with high current capacity and environmental safety.
