C&K COMPONENTS BPA06SBR Side Actuated DIP Switch
The C&K BPA06SBR is a versatile side-actuated DIP switch designed for a wide range of applications, including industrial controls, logic switching for computers and peripherals, and function controlling. Available in both thru-hole and surface mount (SMT) configurations, this switch offers flexibility in design and assembly. Its high-pressure contact system eliminates the need for tape seals during washing, simplifying the cleaning process. The switch is RoHS compliant, ensuring environmental responsibility. The build-a-switch concept allows for customization to meet specific application requirements.
C&K COMPONENTS BPA06SBR Side Actuated DIP Switch Specifications:
- Switch Function: 1 thru 10 and 12 positions available
- Contact Rating: 100 mA max. @ 5 V DC or 25 mA max. @ 24 V DC
- Mechanical and Electrical Life: 1,000 cycles min. @ 5 V DC 10mA
- Contact Resistance: 50 milliohms initial max.
- Insulation Resistance: 100 V DC 100 megohms min.
- Dielectric Withstand Voltage: 300 V AC for 1 minute
- Storage Temperature: -40°C to 85°C
- Operating Temperature: -20°C to 85°C
- Operating Force: 800 grams max.
- Housing Material: PPS, color black (UL94V-0)
- Cover Material: PPS, color black (UL94V-0)
- Actuator Material: PA-6T UL94V-0
- Contacts Material: Beryllium Copper with Gold over Nickel plate
- Terminals Material: Brass, Gold over Nickel plate
- Solderability: Flow solderable and washable (soldering: 260°C for 10 sec. max.)
