C&K COMPONENTS E125MD1CBE Sealed Snap-acting Pushbutton Switch
The C&K E020 Series Sealed Snap-acting Momentary Pushbutton Switches are designed for demanding applications requiring a sealed and reliable switching solution. These switches feature a snap-acting mechanism for positive actuation and are suitable for process sealed environments. They are commonly used in instrumentation, telecommunications equipment, computers, and peripherals. The switches offer long life contact design and are available with various options for plunger height, bushing type, and termination style to meet specific application requirements. RoHS compliant models are available, ensuring environmental compatibility.
C&K COMPONENTS E125MD1CBE Sealed Snap-acting Pushbutton Switch Specifications:
- Contact Rating: 0.4 VA max. @ 20 V AC or DC (B contact material) or 1 AMP @120 V AC or 28 V DC (G contact material)
- Case and Bushing: Glass filled nylon 6/6, flame retardant (UL 94V-0)
- Plunger: Glass filled nylon or glass filled polyester (PBT) (UL 94V-0)
- Switch Support: Brass or steel, matte-tin
- Switch Support Retainer: Stainless steel
- Electrical Life: 60,000 make-and-break cycles at full load
- N.O. & N.C. Contacts (EX25 Models): Copper alloy, with gold plate over nickel plate
- N.O. & N.C. Contacts (EX21 Models): Coin silver, with gold plate over nickel plate
- Contact Resistance: Below 50 mΩ typ. initial @ 2–4 V DC, 100 mA
- Insulation Resistance: 10[9] Ω min.
- Dielectric Strength: 1000 Vrms min. @ sea level
- Common Contacts and Terminals: Copper alloy, with gold plate over nickel plate
- Operating Temperature: –30ºC to 75ºC
- Cap Installation Force: 10 lbs. max. permissible
- Terminal Seal: Epoxy
- Solderability: Per MIL-STD-202F method 208D or EIA RS-186E method 9 (1 hour steam aging)
- Disposable Boot: Vinyl splashproof boot supplied standard
