C&K COMPONENTS SDB04H1BD Low Profile DIP Switch
The C&K Components SDB series low-profile DIP switches offer a compact solution for various applications. These switches are designed with a low-profile configuration to save space and are available in both thru-hole and surface mount models. They are RoHS compliant and suitable for use in industrial controls, logic switching for computers and peripherals, and function controlling applications. The switches feature gold-plated phosphor bronze contacts for reliable performance and are available in full-tube quantities.
C&K COMPONENTS SDB04H1BD Low Profile DIP Switch Specifications:
- Contact Rating: 25 mA @ 24 V DC or 100 mA @ 5 V DC
- Mechanical and Electrical Life: 1,000 cycles at rated loads
- Contact Resistance: 50 mΩ max. initial
- Insulation Resistance: 1000 MΩ between terminals
- Dielectric Withstanding Voltage: 300 V DC min. for 1 minute
- Housing Material: PA46, color black (UL94V-0)
- Cover Material: PA46, color black (UL94V-0)
- Actuator Material: PA46, color white (UL94V-0)
- Contact Material: Gold plated phosphor bronze
- Terminal Material: Gold plate over nickel plated brass
- Tape Seal Material: PI with Silicon coated
- Storage Temperature: -40°C to 85°C
- Operating Temperature: -40°C to 85°C
- Operating Force: 8N max
- Solderability: Dip and look solderability testing per C&K spec. #448
Buy the SDB04H0BD C&K COMPONENTS Low Profile DIP Switch | myMectronic
Purchase the C&K Components SDB04H0BD DIP switch securely and efficiently for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy C&K COMPONENTS SDB04H1BD?
You can click on the BUY or RFQ button to purchase SDB04H1BD from an authorized C&K COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SDB04H1BD?
You can download the SDB04H1BD datasheet or visit the C&K COMPONENTS website for support.
Who is the manufacturer of SDB04H1BD?
C&K COMPONENTS
